Roland GX-24 Manual

1-2 FRAME
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name Parts No. Parts Name
1 22805624 ASSY,FEED MOTOR GX-24 S1 31019135AS SCREW SET,BIND M3*6 NI 100 PCS.
2 22805625 ASSY,SCAN MOTOR GX-24 S2 31019159 SCREW,BINDING M4*6 NI
3 W022805616 ASSY,PLATE BOARD GX-24 S3 31019703AS SCREW,BINDING P-TIGHT 3*8BC 100P
4 22805631 ASSY,PINCH ROLLER L GX-24 S4 31289102AS CUPSCREW SET,M3*6 NI 50 PCS.
5 22805632 ASSY,PINCH ROLLER R GX-24 S5 31049170AS SCREW SET,CAP M3*8 NI 50 PCS.
6 22805633 ASSY,FRAME L GX-24 S6 31049134AS SCREW SET,CAP M4*35 BC 20 PCS.
7 22805634 ASSY,BASE Y-MOTOR GX-24 S7 31049120AS SCREW SET,CAP M4*6 BC 20 PCS.
8 12159508 BUSH,SHAFT OILES 80F-1206 S8 31049141 SCREW,CAP M3*8 BC+SW MEC
9
23415319 CABLE-ASSY,G MOTOR GX-24
S9 31329501AS CLAMP SET,PUSH MOUNT RT30SSF5 20P
10 23415322 CABLE-ASSY,PAPER-SENS GX-24 S10 31019401 SCREW,BINDING M4*6 NI+EXT.TW
11
23415320 CABLE-ASSY,S MOTOR GX-24
S11 31149706AS RING SET,E-RING ETW-10 SUS 20 PCS
12 21715112 FAN,AD7524UB TW S12 31149702AS RING SET,E-RING ETW-3 100 PCS.
13 21995129 FLANGE,MOTOR Y GX-24 S13 31299102AS RIVET SET,NYLON P2655B 20 PCS.
14 22195167 FRAME,CABLE GX-24 S14 31409902 SADDLE,EDGE EDS-3
15 22195165 FRAME,CENTER GX-24 S15 31409801AS SADDLE,LOCKING WIRE LWS-0711Z 20
16 22195162 FRAME,GUIDE GX-24 S16 31169105 SCREW,FLAT M3*10 BC
17 22195163 FRAME,SIDE R GX-24 S17 31199701AS SCREW SET,SET WP M3*3 C 20 PCS.
18 22195166 FRAME,SUPPORT GX-24 S18 31229102 SCREW,TRUSS M2*5 BC
19 21685152 GEAR,H150S10(B6C11.5 POM) S19 31249201AS WASHER SET,PLAIN 3*6*0.5 C 100PCS
20 21655318 HOLDER,IDLE PULLEY GX-24 S20 31249211AS WASHER SET,PLAIN 4.3*7*0.5 C 100P
21 21895135 L-BEARING,RSR9ZMUUC1 + 680LM S21 31029804AS BUSH SET,ROLL 3*5.5 100 PCS.
22 22535562 LABEL,RTC G-ROLLER GX-24 #LA789 S22 31149602AS RING SET,PUSH-ON CS CSTW-4 ACP
23 22485112 LEVER,HANDLE GX-24 S23 31029823 BUSH,ROLL 4*2,5
24 21565102 P-ROLLER TD16S4(B10) TYPE2
25 21545230 PAD,CUTTER GX-24
26 22635376 PAD,DUCT CX-24
27 22055713 PLATE,AXIS GX-24
28 22055710 PLATE,LINK GX-24
29 22055739 PLATE,ORG GX-24
30 22055714 PLATE,HANDLE GX-24
31 22055712 PLATE,SENSOR GX-24
32 22145831 PIN NO.1 (214-831)
33
21975169
PULLEY,T20P2S8+GEAR H55
34 21975170 PULLEY,HD10.8S3(B10)
35 11889102 R-BEARING,D8S4(B3)
36 21885133 R-BEARING,JIS6000ZZ(B8 FL) TW
37 21505116
ROLLER,FD12S4(B4.6C5) TW
38 15099115 SENSOR-INTERRUPTER GP2A25NJ
39 22145393 SHAFT,JOINT PNC-960
40 22145388 SHAFT,PULLEY PNC-960
41 11929116 BELT,1526P2M6
42 22295101 SHAFT,WITH G-ROLLER PNC-960
43 22295306 SHAFT,SQUARE GX-24
44 22175157 SPRING,C P-ROLLER CM-500
45 22625126 SPRING,TENSION GX-24
46 22715491 STAY,BACKUP ROLLER GX-24
47 22715485 STAY,FRAME GUIDE GX-24
48 22715490 STAY,FRAME SIDE R GX-24
49 22715489 STAY,FRAME SIDE L GX-24
50 22715508 STAY,SENSOR F GX-24
51 22715509 STAY,SENSOR R GX-24
52 21425130 WASHER,AXIS GX-24
1-4

Roland GX-24 Specifications

General

Cutting Speed	Up to 20 inches/sec (500 mm/sec)
Distance Accuracy	±0.004 inches (±0.1 mm) or less
Repeatability	±0.1 mm (0.0004 in.) or less
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5 to 40°C (41 to 104°F)
Operating Humidity	35 to 80% RH (non-condensing)
Software Resolution	0.025 mm/step (0.001 in./step)
