7
Mar. 2006 HPD-10
Exploded View (1) Parts List
No
PART CODE PART NAME DESCRIPTION Q’TY
1 # 04129423 PAD HOOP 1
2 # 04124990 PLAYING PLATE 1
3 01900234 CUSHION 1
4 01900245 PRESSURE SHEET SENSOR 1
5 # 73129489 SENSOR BOARD ASSY 1
6 03125589 M R-KNOB MF-ELA BLK/LCG 1
7 03565789 M R-KNOB LF-ELA BLK 1
8 # 04129545 TOP PANEL 1
9 # 04129412 TOP CASE 1
10 # 04129556 REAR PANEL 1
11 22365714 CORD HOOK 1
12 # 04129589 RUBBER SW 1
13 # 73129523 PANEL BOARD ASSY 1
14 # 73129501 MAIN BOARD ASSY 1
15 # 04129534 STAY HOLDER 1
16 # 04129567 BOTTOM COVER 1
17 # 40673812 CAUTION LABEL S 1
18 # 73237490 FOOT ASSY 1
Service Notes(A4)_e 7 ページ ２００６年６月１日 木曜日 午後４時５分
To Next Page
