Roland HPD-10 - Exploded View (3)

9
Mar. 2006 HPD-10
Exploded View (3)
fig.heimen-view1-3
VIEW 2
VIEW 3
e
e
e
VIEW 1
e
e
b
NO.
PART CODE PART NAME DESCRIPTION Q’TY
b 40011245 SCREW 4X12 BINDING P-TITE FE NI 4
e 40011278 SCREW 3X8 BINDING TAPTITE P FE ZC 22
