Roland JD-Xi Midi Implementation

8
3.3 Messages acknowledged for
synchronization
9
System Realtime Messages
7
Timing Clock
Status
F8H
*
Received when Sync Mode parameter (SYSTEM:MIDI) is set to SLAVE.
7
Start
Status
FAH
*
Received when Sync Mode parameter (SYSTEM:MIDI) is set to SLAVE.
7
Continue
Status
FBH
*
The same processing will be carried out as when Start is received.
*
Received when Sync Mode parameter (SYSTEM:MIDI) is set to SLAVE.
7
Stop
Status
FCH
*
Received when Sync Mode parameter (SYSTEM:MIDI) is set to SLAVE.
4. Data transmission
(Sequencer Section)
4.1 Messages transmitted
during playing
Recorded messages are transmitted during playback.
4.2 Messages that are
generated and transmitted
Messages are generated and transmitted to synchronize with other
devices.
9
System Realtime Messages
7
Timing Clock
Status
F8H
7
Start
Status
FAH
7
Stop
Status
FCH
5. Parameter Address Map
*
Transmission of “#” marked address is divided to some packets. For
example, ABH in hexadecimal notation will be divided to 0AH and
0BH, and is sent/received in this order.
*
“<*>” marked address or parameters are ignored when the JD-Xi
received them.
JD-Xi (ModelID = 00H 00H 00H 0EH)
+------------------------------------------------------------------------------+
| Start | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 01 00 00 00 | Setup |
|-------------+----------------------------------------------------------------|
| 02 00 00 00 | System |
|-------------+----------------------------------------------------------------|
| 18 00 00 00 | Temporary Program |
| 19 00 00 00 | Temporary Tone (Digital Synth Part 1) |
| 19 20 00 00 | Temporary Tone (Digital Synth Part 2) |
| 19 40 00 00 | Temporary Tone (Analog Synth Part) |
| 19 60 00 00 | Temporary Tone (Drums Part) |
+------------------------------------------------------------------------------+
*
System
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | System Common |
| 00 03 00 | System Controller |
+------------------------------------------------------------------------------+
*
Temporary Tone
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 01 00 00 | Temporary SuperNATURAL Synth Tone |
| 02 00 00 | Temporary Analog Synth Tone |
| 10 00 00 | Temporary Drum Kit |
+------------------------------------------------------------------------------+
*
Program
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Program Common |
| 00 01 00 | Program Vocal Effect |
| 00 02 00 | Program Effect 1 |
| 00 04 00 | Program Effect 2 |
| 00 06 00 | Program Delay |
| 00 08 00 | Program Reverb |
| 00 20 00 | Program Part (Digital Synth Part 1) |
| 00 21 00 | Program Part (Digital Synth Part 2) |
| 00 22 00 | Program Part (Analog Synth Part) |
| 00 23 00 | Program Part (Drums Part) |
| 00 30 00 | Program Zone (Digital Synth Part 1) |
| 00 31 00 | Program Zone (Digital Synth Part 2) |
| 00 32 00 | Program Zone (Analog Synth Part) |
| 00 33 00 | Program Zone (Drums Part) |
| 00 40 00 | Program Controller |
+------------------------------------------------------------------------------+
*
SuperNATURAL Synth Tone
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | SuperNATURAL Synth Tone Common |
| 00 20 00 | SuperNATURAL Synth Tone Partial (1) |
| 00 21 00 | SuperNATURAL Synth Tone Partial (2) |
| 00 22 00 | SuperNATURAL Synth Tone Partial (3) |
| 00 50 00 | SuperNATURAL Synth Tone Modify |
+------------------------------------------------------------------------------+
*
Analog Synth Tone
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Analog Synth Tone |
+------------------------------------------------------------------------------+
*
Drum Kit
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Drum Kit Common |
| 00 2E 00 | Drum Kit Partial (Key # 36) |
| 00 30 00 | Drum Kit Partial (Key # 37) |
| : | |
| 00 76 00 | Drum Kit Partial (Key # 72) |
+------------------------------------------------------------------------------+
*
Setup
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | (reserve) <*> |
| 00 01 | 0aaa aaaa | (reserve) <*> |
| : | | |

Roland JD-Xi Specifications

General

Pitch wheel	Yes
Product type	Digital/analog synthesizer
Product color	Black
Sound effects	Compression, Delay, Flanger/Digital Signal Processing (DSP), Phaser, Reverberation
Backlight color	Red
Keyboard number of keys	37
Maximum polyphony (notes)	129
Reverberation effects quantity	6
USB ports quantity	1
Display type	LCD
Display number of lines	2 lines
Display number of characters	16
Power source type	AC

Weight and Dimensions

Depth	245 mm
Width	575 mm
Height	85 mm
Weight	2200 g
