RC-20 May. 2001
7
F5367542 10/16V CHIP CAPACITOR C2,C20,C28,C30,C32 on CB.
C4-C9 on PB. C24,C34,C35 on JB 14
F5367546 100/16V CHIP CAPACITOR C18 on CB. C23,C29,C40 on JB 4
02341489 ECPU1C474MA5
MYLAR CAPACITOR(SUBMICRON)
C10 on PB. C1,C9,C10 on JB 4
INDUCTOR, COIL, FILTER
F2449209 SLF7032T-151MR37-2(150UH) COIL L16 on JB 1
F2449210 SLF7032T-4R7M1R7-2(4.7UH) COIL L15 on JB 1
02563478 NFM4516P13C204F EMI FILTER C21 on JB 1
12449381 SBT-0460TF EMI FILTER L14 on JB 1
# 12449386 SBT-0180W EMI FILTER FL1 on JB 1
00903167 N2012Z601T02 FERRITE-BEAD (CHIP) L1-L7 on CB. L1-L10,L12,L13 on JB 19
CRYSTAL, RESONATOR
01899745 AT-41CD2 6.4MHZ CRYSTAL X3 on CB 1
00901912 MA-406 24.576MHZ TE24 CRYSTAL X2 on CB 1
CONNECTOR
F3439160 53015-0210 2P P=2MM CONNECTOR CN6 on JB 1
# F3439165 A2001WR2-10P CONNECTOR CN3 on CB 1
# F3439166 A2001WR2-11P CONNECTOR CN2 on CB 1
# F3439167 A2001WR2-14P CONNECTOR CN1 on CB 1
# F3439164 A2001WR2-8P CONNECTOR CN1 on JB 1
WIRING, CABLE
G3477146 3P L=40x5x5 MM P=2MM RIBBON CABLE CN3 on JB to CN4 on JB 1
# G3487222 WIRING 8P CN3 on PB to CN1 on JB 1
# G3487221 WIRING 10P CN1 on PB to CN3 on CB 1
# G3487220 WIRING 11P CN2 on PB to CN2 on CB 1
# G3487219 WIRING 14P CN2 on JB to CN1 on CB 1
G3487163 WIRING BATTERY L=80MM 2P 1
SCREWS
H5019430 SCREW 2.6x5 BINDING HEAD TAPTITE P FEZC 2
H5019110 SCREW 3x6 PAN HEAD TAPTITE-2 FEZC 12
H5029325 SCREW 3x6 PAN HEAD TAPTITE-2 BZC 5
H5019115 SCREW 3x8 PAN HEAD TAPTITE-2 BZC 2
H5029850 SCREW M4x6 HEXAGON SOCKET BUTTON HEAD FENI 4
H5029852 SCREW 4M3 HEXAGON SOCKET BUTTON HEAD FEBZC 2
40123545 JACK NUT M9x11x2 NI 5
40016467 JACK WASHER M9.2x14x0.5 FENI 5
H5039521 VR ACCESSORY NUT M7 5
H5039413 NYLON WASHER M4.1x7.5x0.5 BLACK 2
H5039414 NYLON WASHER M5.1x9.5x0.5 BLACK 2
40011923 WASHER M9.1x13 INTERNAL TOOTH 2
H5039324 MINI JACK NUT M6 FENI 1
PACKING
# G2567114 CD PACKAGE 1
G2607212 PACKING CASE LOWER 1
# G2627136 PACKING CASE UPPER 1
H2679505 POLYETHYLENE BAG 220x340x0.03 1
G2237614 REAR PAD 1
G2237613 SIDE PAD 1
MISCELLANEOUS
G2257130 BATTERY INSULATING SHEET 1
G2177309 BATTERY TERMINAL(-) 1
G2177308 BATTERY TERMINAL(+) 1
G2177307 BATTERY TERMINAL(+/-) 1
G2357111 CUSHION R 2
G2257131 INSULATING SHEET BOTTOM 1
G2257129 INSULATING SHEET CENTER 1
F2539803 LABEL CAUTION FCC/CE/C-TICK/EMC 1
02123845 LEAF A 2
G2197126 LED GUIDE 1
H2369427 LED SPACER H=8MM 8
# G2197502 MINI JACK HOLDER 1
G2357115 PEDAL FOOT M8 2
2215770201 PEDAL GUIDE BUSH 2
# G2537848 QUICK MANUAL LABEL 1
# F2259116 SHIELD COVER 1
# F2259117 SHIELD SHEET 1
# G2177104 SPRING 2
ACCESSORIES (Standard)
# G6017295 OWNER'S MANUAL JAPANESE 1
# G6017294 OWNER'S MANUAL ENGLISH 1
# G2567113 CD-ROM SAMPLE DATA 1
# G6017447 CD MANUAL 1
40232334 WARRANTY CARD (JAPAN ONLY)
To Next Page
