RC-20 May. 2001
6
PARTS LIST
CASING Q'ty
G2017620 BATTERY CASE V6 1
G2017621 BATTERY COVER 1
G2017148 BOTTOM COVER 1
G2357118 BOTTOM FOOT 2
G2017146 CASE 1
# G2217137 LED PANEL 1
# G2217133 PANEL 1
G2187531 PEDAL L 1
G2357116 PEDAL PLATE 62x53 2
G2187530 PEDAL R 1
H5029851 PEDAL SHAFT 2
# G2217135 REAR PANEL 1
KNOB, BUTTON
G247751001 KEYTOP S BLACK WITH LENS 4
G247751301 KEYTOP S WITHOUT LENS 2
G2477122 R-KNOB 5
SWITCH
01780101 SKQKAB TACT SWITCH SW1,SW2,SW4,SW6-SW8 on PB 6
13129778 SKQKAH TACT SWITCH SW3,SW5 on PB 2
JACK, EXT TERMINAL
13449150MF HTJ-064-12D 6.5MM JACK (STEREO) JK7 on JB 1
13449155MF HTJ-064-12I 6.5MM JACK (MONO) JK1,JK2,JK4,JK5 on JB 4
# F3440404 AJ324A-3C MINI JACK JK3 on JB 1
F344940301 DJ-0711B-020 ADAPTOR JACK JK6 on JB 1
PWB ASSY
# 75D433M000 CENTER PWB ASSY (EXG) 1
# 75D433P001 PANEL PWB ASSY 1
NOTE : 'PANEL PWB ASSY' includes the following parts.
******** PANEL BOARD ASSY
******** JACK BOARD ASSY
IC
# 02780089 UPD703102GJ-33-W05 VER1.01 IC (CPU) IC1 on CB 1
# 02563023 TC58V64AFT IC (FLASH MEMORY) IC6 on CB 1
02451434 AK4552VT IC (AD/DA) IC5 on CB 1
02453389 LC32V4265T-25 IC (DRAM) IC4 on CB 1
02121556 LC24085B-SD1 IC (I/F) IC3 on CB 1
00346445 NJM2100M(TE3) IC (BIPOLAR OP AMP) IC2 on CB 1
15189261 M5218AFP-600E IC (BIPOLAR OP AMP) IC1 on PB. IC2,IC3,IC5,IC6 on JB 5
# 02458090 TC4066BFT(EL) IC (CMOS) IC1 on JB 1
15259118 TC4W66F(TE12L) IC (CMOS) IC4 on JB 1
15259884 TC7S08F(TE85L) IC (CMOS) IC8 on CB 1
01906156 S-8520E33MC-BJS-T2 IC (DC-DC REGULATOR) IC7 on JB 1
02455056 S-80930ALMP-DAT-T2 IC (RESET) IC7 on CB 1
TRANSISTOR
15319107 2SC4116-GR(TE85R) TRANSISTOR Q1,Q2 on PB. Q2 on JB 3
15329103T0 2SK880-GR(TE85R) FET TRANSISTOR Q1,Q11 on JB 2
# 02562867 IRF7606 TRANSISTOR Q10 on JB 1
E
15329521 RN1307(TE85R) TRANSISTOR Q1,Q2 on CB. Q3-Q7,Q12 on JB 8
15329533 RN2307(TE85R) TRANSISTOR Q3-Q10 on CB 8
DIODE
15339119T0 1SS352(TPH3) SWITCHING DIODE D1 on CB. D1-D8 on PB. D11,D12 on JB 11
01019534 1SS355 TE-17 SWITCHING DIODE D9 on JB 1
F5339137 SS14 VF=0.45V DIODE D3,D7 on JB 2
# 02562878 02DZ5.1-Y(TPH3) ZENER DIODE D9 on PB 1
15339120T0 1SS302(TE85R) DIODE ARRAY DA1-DA6 on JB 6
15029342 GL3ED8 LED (RED/GREEN) LED9 on PB 1
F5029126 L-113GDT POWER LED LED17 on PB 1
F5029117 L-312LRD LED (RED) LED4,LED12,LED14,LED15 on PB 4
F5029124 L-34GDSL LED (GREEN) LED2,LED10 on PB 2
1502928100 L-34HDSL LED (RED) LED3,LED5-LED8,LED11,
LED13,LED16 on PB 8
F5029125 L-34YDSL LED (YELLOW) LED1 on PB 1
RESISTOR
# F5399910 0 OHM CHIP RESISTOR (3216TYPE) C3 on JB 1
15399301 0 OHM CHIP RESISTOR (1608TYPE) C25,R45 on JB 2
# F5419716 CRN34103J CHIP RESISTOR RA2,RA7 on CB 2
# F5419715 CRN34680J CHIP RESISTOR RA1,RA3-RA6,RA8-RA12 on CB 10
00566867 RPC05T 100 J CHIP RESISTOR (1608TYPE) R16 on CB 1
00567023 RPC05T 101 J CHIP RESISTOR (1608TYPE) R7,R9,R10,R15,R17,R18,
R22,R23,R30 on CB 9
00567156 RPC05T 102 J CHIP RESISTOR (1608TYPE) R6 on PB R46,R60,R62 on JB 4
00567289 RPC05T 103 J CHIP RESISTOR (1608TYPE) R3,R5,R11,R12,R21,R27,R28,R29 on CB.
R2 on PB.
R1,R3,R11,R12,R15,R21,
R27,R42,R48,R50 on JB 19
00567412 RPC05T 104 J CHIP RESISTOR (1608TYPE) R3 on PB. R6,R13,R14,R47 on JB 5
00567556 RPC05T 105 J CHIP RESISTOR (1608TYPE) R5,R7 on PB. R2,R51 on JB 5
00567167 RPC05T 122 J CHIP RESISTOR (1608TYPE) R1 on PB 1
00567290 RPC05T 123 J CHIP RESISTOR (1608TYPE) R1 on CB. R31 on JB 2
00566890 RPC05T 150 J CHIP RESISTOR (1608TYPE) R20 on CB 1
00567178 RPC05T 152 J CHIP RESISTOR (1608TYPE) R24 on CB 1
00567301 RPC05T 153 J CHIP RESISTOR (1608TYPE) R2 on CB. R33,R58 on JB 3
00567067 RPC05T 221 J CHIP RESISTOR (1608TYPE) R6,R14 on CB 2
00567323 RPC05T 223 J CHIP RESISTOR (1608TYPE) R23,R26,R54,R56 on JB 4
00567334 RPC05T 273 J CHIP RESISTOR (1608TYPE) R8 on PB 1
00567089 RPC05T 331 J CHIP RESISTOR (1608TYPE) R4 on PB 1
00567367 RPC05T 393 J CHIP RESISTOR (1608TYPE) R40 on JB 1
00566967 RPC05T 470 J CHIP RESISTOR (1608TYPE) R26 on CB 1
00567245 RPC05T 472 J CHIP RESISTOR (1608TYPE) R8,R52 on JB 2
00567378 RPC05T 473 J CHIP RESISTOR (1608TYPE) R9,R10 on PB. R4,R5,R9,R10,R16-R20,
R22,R24,R25,R28,R29,R30,
R37,R39,R53,R55,R57 on JB 22
00567501 RPC05T 474 J CHIP RESISTOR (1608TYPE) R59,R61 on JB 2
00567389 RPC05T 563 J CHIP RESISTOR (1608TYPE) R4 on CB. R34,R35,R38,R41 on JB 5
00566990 RPC05T 680 J CHIP RESISTOR (1608TYPE) R8,R13 on CB 2
00567390 RPC05T 683 J CHIP RESISTOR (1608TYPE) R36 on JB 1
00567401 RPC05T 823 J CHIP RESISTOR (1608TYPE) R7 on JB 1
POTENTIOMETER
# F3279805 RD901-40-125F-AF5-00D POT. W/0 CLICK 250KA VR4,VR5 on PB 2
F3279802 RD901-40-125F-B54-00D POT. W/0 CLICK 50KB VR1,VR3 on PB 2
F3279803 RD901-40-125F-B54-11D POT. W/11 CLICKS 50KB VR2 on PB 1
CAPACITOR
# F5359345 0.027U CHIP CAPACITOR (1608TYPE) C6 on JB 1
F5367504 100/6.3V CHIP CAPACITOR C1,C3,C4,C24,C42,C46 on CB 6
F5369601 1/50V CHIP CAPACITOR C1,C2 on PB. C2,C5,C18,C39 on JB 6
01674167 ECUV1H100DCV CHIP CAPACITOR (1608TYPE) C15,C39,C40 on CB. C19,C33 on JB 5
01674278 ECUV1H470JCV CHIP CAPACITOR (1608TYPE) C34,C35 on CB 2
01674334 ECUV1H101JCV CHIP CAPACITOR (1608TYPE) C7,C12,C17,C36,C37 on JB 5
01674423 ECUV1H471JCV CHIP CAPACITOR (1608TYPE) C30,C31 on JB 2
01674567 ECJ1VB1H562K CHIP CAPACITOR (1608TYPE) C13,C44 on CB C14 on JB 3
01674612 ECJ1VB1H103K CHIP CAPACITOR (1608TYPE) C4,C8,C32 on JB 3
01674701 ECJ1VF1E104Z 0.1UF/16VK CHIP CAPACITOR (1608TYPE) C5-C12,C14,C16,C19,C21,C22,
C23,C25,C26,C27,C29,C31,C33,
C36,C37,C38,C41,C43,C47 on CB.
C3 on PB. C11,C28,C38 on JB 30
F5367503 47/6.3V CHIP CAPACITOR C26 on JB 1
SAFETY PRECAUTION:
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
CONSIDERATIONS ON PARTS ORDERING
When ordering any parts listed in the parts list, please specify the following items in the order
sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in
delayed or even undelivered replacement.
The parts marked
# are new (initial
parts).
CB -> CENTER BOARD ASSY,
PB -> PANEL BOARD ASSY,
JK -> JACK BOARD ASSY
To Next Page
