(!7
Earth
"Ground wire installation
is necessary for safety.
(§:
DELAY TIME
Expanding
Knob
Witn
this knob, Delay
Time
can
be increased
up to
1.5 times (Normally, this
should
be set to "x
1"}.
*lf
you use
the instrument other
than electric
guitar
or
bass, a beat may be caused.
If
so, rotate the
DELAY
TIME
Expanding Knob counterclockwise
until the beat stops.
*lf the
Feedback
Level is high, the
SDE-1000
may
start oscillating
at a
high pitch. (If
so, reduce the
-levei or
rotate
the
DELAY TIME
Expanding knob
counterclockwise until the
oscillation stops.}
"When
writing
a
panel setting
or recalling it,
set
this
switch
to the same
level.
*ff
setting such
a
long delay that is
impossible
to
set
in the
"x
1
" mode,
the
delay
time later in
use
in the
"x
1"
mode will not be
longer than
the maximum
deiay time of the
"x
1
"
mode.
"When the Modulation
Switch
is
set to
on,
rotating
the
Delay Time Expanding Knob does not affect
the
Delay Time Display,
*To
see
the current
delay
time,
simply
set
the
Modu-
lation
Switch to the OFF position once.
(0>
MODULATION FOOT
CONTROL Jack
By
connecting the
Foot Control such as
FV-200to
this jack, delay
time can be controlled
with the foot
pedal. Be
sure to
turn
the
Modulation Switch 1/
on, before starting
control. The depth of the modu-
lation can
be
controlled
with
the MODULATION
DEPTH
Knob©
S
Preset
Shift Jack
By
connecting
the Pedal Switch (DP-2) to
this
jack,
four
preset panel settings
can
be
sequencially called.
(2f
PLAY MATE Jack
This is
to
connect
to
the
Pedai Switch (DP-2).
You
can
set a Delay Time of any
length
just by
pressing
the Pedai. The
following shows the
way
to do
that.
1
.
Connect
the DP-2
to the
PLAY
MATE
Jack.
2.
Press
the
pedai, and the Delay
Time Display
will
show
"0.0.0.0."
(Stand-by
mode},
and the
Delay
Time Indicator
remains dark (the
Delay effect is
off).
3.
Press the
DP-2 twice, and the built-in
computer sets
the
Delay Time according
to the interval between
the first
pressing and the second.
4. If
you
press
the Pedal once again, the
DELAY TIME
Display shows
"0.0.0.6."
and the
SDE-1000
is in
the
Stand-by mode again.
•Please
do not touch the
MODULATION
Switch or
DELAY
TIME Expanding Knob during above pro-
cedures. Otherwise
the accurate delay
time may not
be
obtained.
*The longest
Delay Time you can set in the
SDE-
1000 is 750ms,
so
if
you
happen
to set
the
Delay
Tfme exceeding
750ms, the
DELAY
TIME Display
flashes
showing the maximum Delay Time
(750).
In
such a case, press the DP-2 and
set
the Delay Time
again.
@
HOLD Remote Jack
You can turn
the Delay
Hold function on or off
by
connecting the Pedal Switch DP-2
to
this jack. While
the Pedai is depressed, the sound will
be
repeated.
'This effect
cannot be obtained if the delay
time
is
shorter than 20ms. When this
function is
being
used,
the
Memory Channel Selector
(IT,
the Deiay Time
Button
@
or Preset
Shift
Jack yfo':
do
not
work.
*!f
you touch the
Delay
Time Button
:HT
whiie this
Hoid function is
on, the delay sound may be muted.
DELAY TIME
Q
MODULATION
'OTH
CONTROL
REMOTE
PRE5ET
play MATE
®
