Roland TD-12 Manual

10
Apr.2005
PCB ASSY
# 72909878 JACK SHEET ASSY 1
NOTE: ‘JACK SHEET ASSY’ includes the following parts.
# ******** TD-12 TRIG BOARD ASSY Assy(Unit) 1
# ******** TD-12 LCD CN BOARD ASSY Assy(Unit) 1
# ******** TD-12 JACK BOARD ASSY Assy(Unit) 1
NOTE: ‘TD-12 JACK BOARD ASSY’ includes the following parts.
02675701 AC INLET ASSY WIRING W3(AC INLET+GND) 1
02678478 WIRING WIRING W1 CN102 JAB 1
# 72909867 PANEL KEYTOP ASSY 1
NOTE: ‘PANEL KEYTOP ASSY’ includes the following parts.
02013090 F C-KEYTOP MX1H CLR 2
02123467 F C-KEYTOP MX1H BLK 1
02674190 F C-KEYTOP SX1H-A CLR 1
02674212 F C-KEYTOP SX3H-A CLR 2
02674234 F C-KEYTOP SX1H-A BLK 6
# 02674267 F C-KEYTOP SX3H-A BLK 2
# 03892001 F C-KEYTOP SX3H-A GRS 1
02123012 ENCODER HOLDER 1
01455901 LED SPACER LH-36-9 1
03233245 LED SPACER LH-5S-8.7 2
# 72903345 MAIN BOARD ASSY 1
IC
01672634 TC74HC4052AFT(EL) IC (COMS) IC36 on MAB ,IC17,IC20,IC21 TRB 3
+1
01908701 TC74VHC14FT(EL) IC (CMOS) IC208 on MAB ,IC16,IC22 TRB 2
+1
15289128 BA10324AF IC (OP AMP) IC35 on MAB
,IC1R,IC19,IC18,IC1S,IC1P,IC1N,IC1M,IC1
L,IC1K,IC1J,IC1T TRB
11
+1
15189261 M5218AFP-600E IC (BIPOLAR OP AMP) IC101,IC102,IC105 JAB
,IC28,IC30,IC26,IC15,IC23,IC17 on
MAB,IC4,IC3,IC2 PAB,IC7 TRB
1
+3
+3
+6
02456756 TC74VHCT04AFT(EL) IC (CMOS) IC103 JAB 1
02900545 PC410LKNIP IC (PHOTO COUPLER) IC104 JAB 1
03785601 SN74LV04APWR IC (CMOS) IC1 PAB 1
# 03897678 UPD703106AGJ-099-UEM IC (CPU)(TD12M 1.00) IC2 on MAB 1
# 03897689 UPD703106AGJ-100-UEM IC (CPU)(TD12T 1.00) IC10 on MAB 1
01455956 TC223C660CF-503 IC (RA08-503) IC52 on MAB 1
# 03786223 CY62146DV30LL-55ZSXIT IC (SRAM) IC3 on MAB 1
03787889 M11L416256SA-35TG 0.20 IC (DRAM) IC300 on MAB 1
03453490 MR27V12800J-OT4TN (TD20-1) IC (MASK ROM) IC205 on MAB 1
03453501 MR27V12800J-OT5TN (TD20-2) IC (MASK ROM) IC206 on MAB 1
03341590 TC58FVM5B2ATG65BAH IC (FLASH MEMORY) IC1 on MAB 1
03237689 M12L64164A-7T IC (MEMORY DRAM) IC4 on MAB 1
03670356 AK4626VQP IC (AD/DA) IC25 on MAB 1
01458401 TC74LVX4245FS(EL) IC (TTL) IC64,IC75,IC72,IC66 on MAB 4
01901623 TC74LVXC3245FS IC (CMOS) IC53,IC49 on MAB 2
01349590 TC7WU04FU(TE12L) IC (CMOS) IC5 on MAB 1
01679090 TC74VHC08FT(EL) IC (CMOS) IC69,IC200,IC50,IC7 on MAB 4
01783523 TC74VHCT245AFT(EL) IC (CMOS) IC54 on MAB 1
02456734 TC74VHCT74AFT(EL) IC (CMOS) IC56 on MAB 1
02565212 SN74LV245A-PW IC (CMOS) IC63,IC65,IC68,IC70,IC71,IC74 on MAB 6
03016167 TC74VHCT08AFT(EL) IC (CMOS) IC61,IC8,IC41,IC40,IC51 on MAB 5
01455301 TC7WH04FU(TE12L) IC (CMOS) IC400 on MAB 1
15289106 M5238AFP-600C IC (JFET OP AMP) IC6 on MAB 1
03347023 TA79L05F(TE12L) IC (REGULATOR) IC31 on MAB 1
15289402 TA78L05F(TE12L) IC (REGULATOR) IC29 on MAB 1
03123734 PQ033DZ01ZP IC (REGULATOR) IC201 on MAB 1
15199937 M51953BFP-600C IC (RESET) IC9 on MAB 1
TRANSISTOR
15319115 2SC4213-A(TE85L) TRANSISTOR Q104,Q102,Q103,Q101 JAB ,Q9,Q6 on MAB 4
+2
00239801 DTA114EU T-106 TRANSISTOR Q106 JAB ,Q1 on MAB 1
+1
00239812 DTC114EUT106 TRANSISTOR Q105 JAB ,Q13,Q4,Q2 on MAB 1
+3
01783612 RN2426(TE85L) TRANSISTOR Q6,Q4,Q3,Q5,Q1,Q2 PAB 6
01121278 2SA1576A T106 QRS TRANSISTOR Q3,Q11 on MAB 2
15309103 2SA1202-Y(TE12L C) TRANSISTOR Q10,Q7 on MAB 2
01121289 2SC4081 T106 QRS TRANSISTOR Q21,Q20,Q19,Q18,Q17,Q12,Q22,Q23,Q16
on MAB
9
15319102 2SC2882-Y(TE12L.C) TRANSISTOR Q5,Q8 on MAB 2

Roland TD-12 Specifications

General

Instruments	560
Kits	50 Preset, 50 User
MIDI	In, Out, Thru
Effects	EQ
Trigger Inputs	12
Power Supply	AC Adaptor
Pads	Compatible with Roland V-Drums pads
