7
TD-12
EXPLODED VIEW PARTS LIST
[Parts]
[Screws]
No PART CODE PART NAME DESCRIPTION Q’TY
1 03891990 CASING TOP PANEL 1
2 03891878 CASING LED COVER 1
3 03891923 CASING RUBBER SW ESCUTCHEON 1
4 03891989 KNOB,BUTTON RUBBER SW 1
5 03891934 CASING D S-ESCUTCHEON SX2H-A BLK L=30 1
6 03453845 CASING D S-ESCUTCHEON SX4H-A BLK L=30 1
7 72909867 PWB ASSY PANEL KEYTOP ASSY 1
8 02670889 WIRING, CABLE BAN CARD BNCD-P=1.00-K-26-80 1
9 03891834 WIRING, CABLE BAN CARD BNCD-P=1.00-K-40-180 1
10 02674234 KNOB,BUTTON F C-KEYTOP SX1H-A BLK 6
11 02674212 KNOB,BUTTON F C-KEYTOP SX3H-A CLR 2
12 02674267 KNOB,BUTTON F C-KEYTOP SX3H-A BLK 2
13 02674190 KNOB,BUTTON F C-KEYTOP SX1H-A CLR 1
14 03892001 KNOB,BUTTON F C-KEYTOP SX3H-A GRS 1
15 02013090 KNOB,BUTTON F C-KEYTOP MX1H CLR 2
16 02123467 KNOB,BUTTON F C-KEYTOP MX1H BLK 1
17 03895156 MISCELLANEOUS DISPLAY CUSHION 1
18 03891889 CHASSIS PWR SPLY HOLDER 2
19 03230690 DISPLAY UNIT LCD SCLCMEAMNI0065 1
21 02789112 WIRING, CABLE BAN CARD BNCD-P=1.00-K-10-100 1
22 03891890 CHASSIS LCD HOLDER 1
23 40232123 MISCELLANEOUS ACETATE TAPE NITTO #5 BLACK W20MM 30M 20P 4
24 03891978 CHASSIS PWB HOLDER MAIN 3
25 03782334 POWER SUPPLY UNIT SWITCHING REGULATOR A1DU2L3B184 1
26 02894367 MISCELLANEOUS INSULATING COVER DA-2496 SW-PS 1
27 03453512 WIRING, CABLE WIRING W1 1
29 03453667 WIRING, CABLE BAN CARD BNCD-P=1.00-K-28-50 1
30 03902767 MISCELLANEOUS INSULATING SHEET 1
31 72903345 PWB ASSY MAIN BOARD ASSY 1
33 03453723 WIRING, CABLE BAN CARD BNCD-P=1.00-K-40-60 1
34 03891845 CASING BOTTOM COVER 1
35 01235378 MISCELLANEOUS FOOT 4
36 03891901 MISCELLANEOUS PANEL SHEET 1
37 03891867 CASING DISPLAY COVER 1
38 22485303 KNOB,BUTTON D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
39 03125589 KNOB,BUTTON M R-KNOB MF-ELA BLK/LCG 3
40 22485295 KNOB,BUTTON D S-KNOB S BLK/LCG 6
41 12499175 KNOB,BUTTON BUTTON JSPUE001A 1
72909878 PWB ASSY JACK SHEET ASSY 1
NOTE: ‘JACK SHEET ASSY’ includes the following parts.
20 ******** PWB ASSY LCD CN BOARD ASSY 1
28 ******** PWB ASSY JACK BOARD ASSY 1
32 ******** PWB ASSY TRIG BOARD ASSY 1
No PART CODE PART NAME DESCRIPTION Q’TY
A 40011312 SCREWS SCREW 3X8 BINDING TAPTITE P BZC 5
B 40011090 SCREWS SCREW 3X6 BINDING TAPTITE B BZC 32
C 40011023 SCREWS
SCREW M3X8 PAN B-TITE FECM
4
D 40011490 SCREWS SCREW M3X6 PAN MACHINE W/SW BZC 6
E 40011123 SCREWS SCREW 4X8 BINDING TAPTITE B BZC 2
F 40010345 SCREWS SCREW M4X10 BINDING MACHINE FE BZC 1
G 40011745 SCREWS HEX NUT M4 SPRING NUT FE ZC 1
H 40238145 SCREWS SCREW M5X12 TRUSS BZC 4
I 40569934 SCREWS SCREW M3X6 SPW NI HEX SOCKET SPW NI 5
To Next Page
