TD-12 MIDI Implementation
❍ Foot Controller (Controller number 4)
Status 2nd byte 3rd byte
BnH 04H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP]-[MIDI]-[CTRL] Pedal CC to FOOT changes the hi-hat control
pedal position.
* The strike position of the pad corresponding to the note number received
changes immediately after [SETUP]-[MIDI]-[CTRL] Snare CC (for the SNARE
pad head and rim), Ride CC (for the RIDE pad bow), or Toms CC (for the TOM
1-3 and AUX 1-2 pad rims) is set to FOOT.
* During recording, the sequencer data is recorded to the TD-12 in accordance
with the above settings as “Pedal CC messages,” “Snare CC messages,” “Ride
CC messages,” and “Toms CC messages.”
❍ Data Entry (Controller number 6, 38)
Status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
mm, ll = the value of the parameter specified by RPN
mm = MSB, ll = LSB
* Only the channels assigned to the backing part can be received.
* Refer to the RPN item.
* Not recorded in the sequencer.
❍ Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Volume: 00H - 7FH (0 - 127)
* Changes the volume for the part. Not indicated in the display.
* Not recorded in the sequencer.
❍ Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right)
* Only the channels assigned to the backing part can be received.
* Changes the pan ([PATTERN]-[PART]-[MIXER]-[PAN]) for the part. Not
indicated in the display.
* Not recorded in the sequencer.
❍ Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP]-[MIDI]-[CTRL] Pedal CC to EXPRESSION changes the hi-hat
control pedal position.
* The strike position of the pad corresponding to the note number received
changes immediately after [SETUP]-[MIDI]-[CTRL] Snare CC (for the SNARE
pad head and rim), Ride CC (for the RIDE pad bow), or Toms CC (for the TOM
1-3 and AUX 1-2 pad rims) is set to EXPRESSION.
* During recording, the sequencer data is recorded to the TD-12 in accordance
with the above settings as “Pedal CC messages,” “Snare CC messages,” “Ride
CC messages,” and “Toms CC messages.”
❍ General Purpose Controller 1 (Controller number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP]-[MIDI]-[CTRL] Pedal CC to GENERAL1 changes the hi-hat
control pedal position.
* The strike position of the pad corresponding to the note number received
changes immediately after [SETUP]-[MIDI]-[CTRL] Snare CC (for the SNARE
pad head and rim), Ride CC (for the RIDE pad bow), or Toms CC (for the TOM
1-3 and AUX 1-2 pad rims) is set to GENERAL1.
* During recording, the sequencer data is recorded to the TD-12 in accordance
with the above settings as “Pedal CC messages,” “Snare CC messages,” “Ride
CC messages,” and “Toms CC messages.”
❍ General Purpose Controller 2 (Controller number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP]-[MIDI]-[CTRL] Pedal CC to GENERAL2 changes the hi-hat
control pedal position.
* The strike position of the pad corresponding to the note number received
changes immediately after [SETUP]-[MIDI]-[CTRL] Snare CC (for the SNARE
pad head and rim), Ride CC (for the RIDE pad bow), or Toms CC (for the TOM
1-3 and AUX 1-2 pad rims) is set to GENERAL2.
* During recording, the sequencer data is recorded to the TD-12 in accordance
with the above settings as “Pedal CC messages,” “Snare CC messages,” “Ride
CC messages,” and “Toms CC messages.”
