MIDI Implementation
5
 Reset All Controllers (Controller number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, the following controllers will be set to their reset
values.
Controller Reset value
Pitch Bend Change ±0 (center)
Polyphonic Key Pressure 0 (o)
Modulation 0
Breath Controller 0
Foot Controller 0
Expression 0
General Purpose Controller 1 - 4 0
Hold 1 0 (o)
RPN
unset; previously set data will not
change
* When recording, a control message carrying the reset value will be created and
recorded.
 All Notes O (Controller number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When All Notes O is received, all notes on the corresponding channel will be
turned o. However if Hold 1 is ON, the sound will be continued until these are
turned o.
* In the recording mode, “Note O message” will be created for corresponding Note
On message, and will be recorded.
 OMNI OFF (Controller number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes O is received.
 OMNI ON (Controller number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes O is received.
 MONO (Controller number 126)
Status 2nd byte 3rd byte
BnH 7EH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = mono number: 00H - 10H (0 - 16)
* The same processing will be carried out as when All Sound O or All Notes O is
received.
 POLY (Controller number 127)
Status 2nd byte 3rd byte
BnH 7FH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Sound O or All Notes O is
received.
 System Realtime Message
* Following System Realtime Messages cannot be recorded in recording mode.
 Timing Clock
Status
F8H
* Recognized only when the [TEMPO] - [SYNC] Sync Mode is set at “EXTERNAL” or
“AUTO.”
 Start
Status
FAH
* Recognized only when the [TEMPO] - [SYNC] Sync Mode is set at “EXTERNAL,” “AUTO”
or “REMOTE.”
 Continue
Status
FBH
* Recognized only when the [TEMPO] - [SYNC] Sync Mode is set at “EXTERNAL,” “AUTO”
or “REMOTE.”
 Stop
Status
FCH
* Recognized only when the [TEMPO] - [SYNC] Sync Mode is set at “EXTERNAL,” “AUTO”
or “REMOTE.”
