MIDI Implementation
8
Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
* The part volume ([PATTERN] - [PART] - [MIXER] - [VOLUME]) information is
transmitted when set.
* The volume of each part in a pattern is transmitted when the pattern is selected
(except for the drum part).
Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right)
* This is transmitted only on the channels which are assigned to the backing part.
* The backing part pan ([PATTERN] - [PART] - [MIXER] - [PAN]) information is
transmitted when set.
* The backing part pan is transmitted when the pattern is selected.
Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* This is transmitted only on the channel which is assigned to the drum part.
* When [SETUP] - [MIDI] - [CTRL] HH Pedal CC is set to “EXPRESSION, this is transmitted
when the hi-hat control pedal is adjusted. When the HI-HAT pad is struck, this is
transmitted as a pedal position message before Note On.
* When the following four things are set, strike position data will be transmitted
before the note-on data when a pad is struck.
When, under [SETUP] - [MIDI] - [CTRL], any of the following is set to
“EXPRESSION” Snare CC (for head and rim of SNARE pad), Ride CC (for bow of
RIDE pad), or Toms/AUXs CC (for head and rim of TOM 1–4, AUX 1–4 pads).
When Trig Type for [TRIGGER] - [SENS] is set to a type that provides for the
detection of the striking point.
When Head and Rim for Position Detect for [TRIGGER] - [ADVANCE] - [POSI] are
set to “ON.
When Position Ctrl for [INST] - [CONTROL] - [POSI] is set to “ON.
* “HH Pedal CC message, “Snare CC message, “Ride CC message, and Toms/AUXs
CC message sequencer data recorded to the TD-30 is transmitted during the
performance in accordance with the above settings.
General Purpose Controller 1 (Controller number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* This is transmitted only on the channel which is assigned to the drum part.
* When [SETUP] - [MIDI] - [CTRL] HH Pedal CC is set to “GENERAL 1”, this is transmitted
when the hi-hat control pedal is adjusted. When the HI-HAT pad is struck, this is
transmitted as a pedal position message before Note On.
* When the following four things are set, strike position data will be transmitted
before the note-on data when a pad is struck.
When, under [SETUP] - [MIDI] - [CTRL], any of the following is set to “GENERAL
1” Snare CC (for head and rim of SNARE pad), Ride CC (for bow of RIDE pad), or
Toms/AUXs CC (for head and rim of TOM 1–4, AUX 1–4 pads).
When Trig Type for [TRIGGER] - [SENS] is set to a type that provides for the
detection of the striking point.
When Head and Rim for Position Detect for [TRIGGER] - [ADVANCE] - [POSI] are
set to “ON.
When Position Ctrl for [INST] - [CONTROL] - [POSI] is set to “ON.
* “HH Pedal CC message, “Snare CC message, “Ride CC message, and Toms/AUXs
CC message sequencer data recorded to the TD-30 is transmitted during the
performance in accordance with the above settings.
General Purpose Controller 2 (Controller number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* This is transmitted only on the channel which is assigned to the drum part.
* When [SETUP] - [MIDI] - [CTRL] HH Pedal CC is set to “GENERAL 2”, this is transmitted
when the hi-hat control pedal is adjusted. When the HI-HAT pad is struck, this is
transmitted as a pedal position message before Note On.
* When the following four things are set, strike position data will be transmitted
before the note-on data when a pad is struck.
When, under [SETUP] - [MIDI] - [CTRL], any of the following is set to “GENERAL
2” Snare CC (for head and rim of SNARE pad), Ride CC (for bow of RIDE pad), or
Toms/AUXs CC (for head and rim of TOM 1–4, AUX 1–4 pads).
When Trig Type for [TRIGGER] - [SENS] is set to a type that provides for the
detection of the striking point.
When Head and Rim for Position Detect for [TRIGGER] - [ADVANCE] - [POSI] are
set to “ON.
When Position Ctrl for [INST] - [CONTROL] - [POSI] is set to “ON.
* “HH Pedal CC message, “Snare CC message, “Ride CC message, and Toms/AUXs
CC message sequencer data recorded to the TD-30 is transmitted during the
performance in accordance with the above settings.
