MIDI Implementation
9
General Purpose Controller 3 (Controller number 18)
Status 2nd byte 3rd byte
BnH 12H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* This is transmitted only on the channel which is assigned to the drum part.
* When [SETUP] - [MIDI] - [CTRL] HH Pedal CC is set to “GENERAL 3, this is transmitted
when the hi-hat control pedal is adjusted. When the HI-HAT pad is struck, this is
transmitted as a pedal position message before Note On.
* When the following four things are set, strike position data will be transmitted
before the note-on data when a pad is struck.
When, under [SETUP] - [MIDI] - [CTRL], any of the following is set to “GENERAL
3” Snare CC (for head and rim of SNARE pad), Ride CC (for bow of RIDE pad), or
Toms/AUXs CC (for head and rim of TOM 1–4, AUX 1–4 pads).
When Trig Type for [TRIGGER] - [SENS] is set to a type that provides for the
detection of the striking point.
When Head and Rim for Position Detect for [TRIGGER] - [ADVANCE] - [POSI] are
set to “ON.
When Position Ctrl for [INST] - [CONTROL] - [POSI] is set to “ON.
* “HH Pedal CC message, “Snare CC message, “Ride CC message, and Toms/AUXs
CC message sequencer data recorded to the TD-30 is transmitted during the
performance in accordance with the above settings.
General Purpose Controller 4 (Controller number 19)
Status 2nd byte 3rd byte
BnH 13H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* This is transmitted only on the channel which is assigned to the drum part.
* When [SETUP] - [MIDI] - [CTRL] HH Pedal CC is set to “GENERAL 4, this is transmitted
when the hi-hat control pedal is adjusted. When the HI-HAT pad is struck, this is
transmitted as a pedal position message before Note On.
* When the following four things are set, strike position data will be transmitted
before the note-on data when a pad is struck.
When, under [SETUP] - [MIDI] - [CTRL], any of the following is set to “GENERAL
4” Snare CC (for head and rim of SNARE pad), Ride CC (for bow of RIDE pad), or
Toms/AUXs CC (for head and rim of TOM 1–4, AUX 1–4 pads).
When Trig Type for [TRIGGER] - [SENS] is set to a type that provides for the
detection of the striking point.
When Head and Rim for Position Detect for [TRIGGER] - [ADVANCE] - [POSI] are
set to “ON.
When Position Ctrl for [INST] - [CONTROL] - [POSI] is set to “ON.
* “HH Pedal CC message, “Snare CC message, “Ride CC message, and Toms/AUXs
CC message sequencer data recorded to the TD-30 is transmitted during the
performance in accordance with the above settings.
Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
* This is transmitted only on the channels which are assigned to the backing part.
* Transmitted only when the device is in play for pattern in which Hold 1 is recorded.
Eect 1 Depth (Reverb Send Level)
(Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Reverb send level: 00H - 7FH (0 - 127)
* This is transmitted only on the channels which are assigned to the backing part.
* The backing part reverb send level ([PATTERN] - [PART] - [MIXER] - [REV SND]) is
transmitted when set.
* The backing part reverb send level is transmitted when the pattern is selected..
Eect 2 Depth (Chorus Send Level)
(Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Chorus send level: 00H - 7FH (0 - 127)
* This is transmitted only on the channels which are assigned to the backing part.
* The backing part chorus send level ([PATTERN] - [PART] - [MIXER] - [CHO SND]) is
transmitted when set.
* The backing part chorus send level is transmitted when the pattern is selected.
RPN MSB/LSB (Controller number 101, 100)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte of parameter number specied by RPN(MSB)
ll = lower byte of parameter number specied by RPN(LSB)
This device receives the following RPNs.
RPN Data Entry
MSB, LSB MSB, LSB Explanation
00H, 00H mmH, 00H Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
7FH, 7FH —, — RPN null
mm,ll: ignored
set condition where RPN is unspecied.
* This is transmitted only on the channels which are assigned to the backing part.
* The backing part bend range ([PATTERN] - [PART] - [BACKING] Bend Range) is
transmitted when set.
* The backing part bend range is transmitted when the pattern is selected.
Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
* Not transmitted when [SETUP] - [MIDI] - [PROG] TX Switch is set to “OFF.
* When a drum kit is selected, the corresponding program number ([SETUP] - [MIDI] -
[PROG] - [DRM KIT]) is transmitted.
* When a percussion set is selected, the corresponding program number ([SETUP] -
[MIDI] - [PROG] - [PRC SET]) is transmitted.
* When a backing part instrument is selected, the corresponding program number is
transmitted. Refer to the “Backing Instrument List” in the Data List.
* When a pattern is selected, the program number for the instrument in each part is
transmitted (except for the drum part).
