Roland TrueVIS Series User Manual

6
All TrueVIS Models
Replacing the Contour Cutter Blade &
Proper Blade Settings
• Rough Estimate for the Amount of Blade Extension (When Creating a Sticker)
Set the amount of blade extension (1) to an amount that is the sum of the thickness of the material portion (2) and half
(4) which is the thickness of the backing paper (3).
• Rough Estimate for the Amount of Blade Extension (When Cutting Perforated Lines)
Set the amount of blade extension (1 ) so that when the cutter pierces the media (2), the blade extends slightly.
For information about the output settings for cutting perforated lines, refer to the documentation for
VersaWorks.
Extending the blade out too far will damage the blade and cutter pad “protection strip”. The life expectancy of
these items will be reduced.
