RS-232 Command Reference
10
System-related Operations
Item
Sent
Commands
Response
Command
Parameter
Set HDCP on/o stxHCP:a; ACK a: 0 (OFF), 1 (ON)
Set Auto Scan on/o stxASN:a; ACK a: 0 (OFF) 1 (ON)
Call up memory stxMEM:a; ACK a: 0 (A-1), 1 (A-2), 2 (A-3), 3 (A-4), 4 (B-1), 5 (B-2), 6 (B-3), 7 (B-4)
Acquire status of operation-panel buttons stxQPL:a; stxQPL:b;
ACK
Sent command parameters
a: 0 (PGM), 1 (PST), 2 (PinP), 3 (SPLIT), 4 (DSK), 5 (TRANSITION), 6 (OUTPUT FADE),
7 (A/B fader), 8 (ALL)
Response command parameters
When a=0, b: 0 (CH 1)–3 (CH 4) PGM
When a=1, b: 0 (CH 1)–3 (CH 4) PST
When a=2, b: 0 (OFF), 1 (ON) [PinP] button
When a=3, b: 0 (OFF), 1 (ON) [SPLIT] button
When a=4, b: 0 (OFF), 1 (ON) [DSK] button
When a=5, b: 0 (WIPE), 1 (MIX), 2 (CUT) TRANSITION buttons
When a=6, b: 0–255 Output fade level
0: black, 255: white, 128: center
When a=7, b: 0–255 Output level of A/B fader
0: bus B end, 255: bus A end, 128: center
When a=8, sends all information described above. Example: stxQPL:0,1,0,1,1,0,100,255;
Acquire status of V-1SDI stxACS; ACK
Version information stxVER; stxVER:V-1SDI,a; a: Version * The version info is ASCII text strings.
Flow control XON
Flow control XOFF
Commands Spontaneously Sent from the V-1SDI
Item
Sent
Commands
Response
Command
Parameter
Announce status of operation-panel buttons stxQPL:b; Parameter information is similar to QPL (8: ALL) response.
* This is enabled when the “RS-232 PANEL STATUS” setting under SYSTEM (page 16/16) on
the SETUP menu is set to “ON.”
* This sends the command when the channel is switched or bus A or B is switched.
Error detected stxERR:a; a: 0 (syntax error) The received command contains an error.
5 (out of range error) An argument of the received command is out of range.
Flow control XON
Flow control XOFF
