Roland V-1SDI Reference Manual

Menu List
5
AUDIO Menu
(Pressing and holding the [AUDIO] button for 2 seconds or longer)
Setting item Value Explanation
AUDIO LEVEL (page 1/15)
SDI1
:
SDI3
HDMI3
HDMI4
AUDIO
MIC
INPUT LEVEL -INF–0.0–+6.0 dB This adjusts the volume level of the respective input audio streams.
MASTER OUTPUT LEVEL -INF–0.0–+6.0 dB This adjusts the volume level of output audio.
AUDIO FOLLOW (page 2/15)
A.FOLLOW
SDI1
:
SDI3
HDMI3
HDMI4
OFF, ON
This sets the Audio Follow feature on or o for the respective input video streams.
Setting this to “ON” automatically mutes out audio when the video channel is not selected.
AUDIO IN OFF, 1–4
This sets the video channel to interlink by Audio Follow with audio input via AUDIO IN.
Audio input via AUDIO IN is muted on other than the specied video.
MIC IN OFF, 1–4
This sets the video channel to interlink by Audio Follow with audio input via MIC.
Audio input via MIC is muted on other than the specied video.
AUDIO DELAY (page 3/15)
CH1 SDI
:
CH3 SDI
CH3 HDMI
CH4 HDMI
AUDIO IN
MIC IN
0.0–500.0 ms This adjusts the delay time for audio inputs.
SDI1 IN–SDI3 IN, HDMI3 IN, HDMI4 IN, ADUIO IN (page 4/15–9/15)
EQ Hi -15–0–15 dB This boosts or attenuates the high band.
EQ Hi FREQ 1.00–10.0–20.0 kHz This adjusts the center frequency when changing the sound quality in the high band.
EQ Mid -15–0–15 dB This boosts or attenuates the middle band.
EQ Mid FREQ 20 Hz–500 Hz–20.0 kHz This adjusts the center frequency when changing the sound quality in the middle band.
EQ Mid Q 0.5–16.0 This adjusts the width of the frequency band when boosting or attenuating the middle band.
EQ Lo -15–0–15 dB This boosts or attenuates the low band.
EQ Lo FREQ 20–100–500 Hz This adjusts the center frequency when changing the sound quality in the low band.
MIC IN (page 10/15)
EQ Hi -15–0–15 dB This boosts or attenuates the high band.
EQ Hi FREQ 1.00–10.0–20.0 kHz This adjusts the center frequency when changing the sound quality in the high band.
EQ Mid -15–0–15 dB This boosts or attenuates the middle band.
EQ Mid FREQ 20 Hz–500 Hz–20.0 kHz This adjusts the center frequency when changing the sound quality in the middle band.
EQ Mid Q 0.5–16.0 This adjusts the width of the frequency band when boosting or attenuating the middle band.
EQ Lo -15–0–15 dB This boosts or attenuates the low band.
EQ Lo FREQ 20–100–500 Hz This adjusts the center frequency when changing the sound quality in the low band.
HPF OFF, ON This sets the high-pass lter on or o.
MIC IN (page 11/15)
COMP OFF, ON This sets the compressor on or o.
THRESHOLD -50–-16–0 dB
This sets the level used as the threshold when compressing audio. Compression is applied to audio
that exceeds the level set here.
RATIO 1.0:1–INF:1
This species the degree of compression applied to the audio. The state in which no compression is
applied is dened as “1.”
ATTACK 0.2–50–100 ms This sets the time until compression starts when audio exceeding the threshold is input.
RELEASE 30–500–5000 ms This adjusts the length of time until compression ends after audio falls below the threshold.
GATE OFF, ON This sets gate on or o.
THRESHOLD -50–-36–0 dB
This sets the level used as the threshold for removing audio. Audio below the level set here is
removed.
RELEASE 30–800–5000 ms This adjusts the length of time until the audio is fully attenuated after audio falls below the threshold.

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
