RS-232 Command Reference
8
List of Commands
Video-related Operations
Item
Sent
Commands
Response
Command
Parameter
Select bus A channel number stxPGM:a; ACK a: 0 (CH 1)–3 (CH 4)
Select bus B channel number stxPST:a; ACK a: 0 (CH 1)–3 (CH 4)
Specify transition eect stxTRS:a; ACK a: 0 (WIPE), 1 (MIX), 2 (CUT)
Set transition time stxTIM:a; ACK a: 0 (0.0 sec)–40 (4.0 sec)
Press the [AUTO] button stxATO; ACK
Press the [PinP] button stxPIP; ACK
Press the [SPLIT] button stxSPT; ACK
Press the [DSK] button stxDSK; ACK
Select input connector for INPUT 3 stxIPS:a; ACK a: 0 (AUTO), 1 (SDI 3) ,2 (HDMI 3)
Select scaling type for INPUT 4 stxISC:a; ACK a: 0 (FULL), 1 (LETTERBOX), 2 (CROP), 3 (DOT BY DOT)
Adjust horizontal position of INPUT 4 stxIHP:a; ACK a: -1920–1920
* Only commands containing a multiple of 8 are accepted.
Adjust vertical position of INPUT 4 stxIVP:a; ACK a: -1080–1080
* Only commands containing a multiple of 8 are accepted.
Adjust zoom rasio of INPUT 4 stxIZM:a; ACK a: 50–200
Assign video output of the PVW connector (SDI) stxOPS:a; ACK a: 0 (MULTI-VIEW), 1 (PST), 2 (PGM)
Assign video output of the MULTI-VIEW connector (HDMI) stxOMS:a; ACK a: 0 (MULTI-VIEW), 1 (PST), 2 (PGM)
Change DSK KEY LEVEL stxKYL:a; ACK a: 0–255
Adjust position of PinP 1/4-size inset screen
* PinP inset screen assigned to the [PinP] button
stxPQA:a,b; ACK a: 0–255 Horizontal position
b: 0–255 Vertical position
Adjust position of PinP 1/2-size inset screen
* PinP inset screen assigned to the [PinP] button
stxPHA:a,b; ACK a: 0–255 Horizontal position
b: 0–255 Vertical position
Adjust position of PinP 1/4-size inset screen
* PinP inset screen assigned to the [SPLIT] button
stxPQB:a,b; ACK a: 0–255 Horizontal position
b: 0–255 Vertical position
Adjust position of PinP 1/2-size inset screen
* PinP inset screen assigned to the [SPLIT] button
stxPHB:a,b; ACK a: 0–255 Horizontal position
b: 0–255 Vertical position
Adjust split-composition “SPLIT-HC” position
* Split-composition video assigned to the [PinP] button
stxSHA:a,b; ACK a: 0–255 Vertical position of PGM video (displayed on the left)
b: 0–255 Vertical position of PST video (displayed on the right)
Adjust split-composition “SPLIT-VC” position
* Split-composition video assigned to the [PinP] button
stxSVA:a,b; ACK a: 0–255 Horizontal position of PGM video (displayed above)
b: 0–255 Horizontal position of PST video (displayed below)
Adjust split-composition “SPLIT-HC” position
* Split-composition video assigned to the [SPLIT] button
stxSHB:a,b; ACK a: 0–255 Vertical position of PGM video (displayed on the left)
b: 0–255 Vertical position of PST video (displayed on the right)
Adjust split-composition “SPLIT-VC” position
* Split-composition video assigned to the [SPLIT] button
stxSVB:a,b; ACK a: 0–255 Horizontal position of PGM video (displayed above)
b: 0–255 Horizontal position of PST video (displayed below)
Acquire information on input connector selected for INPUT 3 stxQIS; stxQIS:a;
ACK
a: 0 (SDI), 1 (HDMI)
