Menu List
6
Setting item Value Explanation
AUDIO OUTPUT (page 12/15)
EQ Hi -15–0–15 dB This boosts or attenuates the high band.
EQ Hi FREQ 1.00–10.0–20.0 kHz This adjusts the center frequency when changing the sound quality in the high band.
EQ Mid -15–0–15 dB This boosts or attenuates the middle band.
EQ Mid FREQ 20 Hz–500 Hz–20.0 kHz This adjusts the center frequency when changing the sound quality in the middle band.
EQ Mid Q 0.5–16.0 This adjusts the width of the frequency band when boosting or attenuating the middle band.
EQ Lo -15–0–15 dB This boosts or attenuates the low band.
EQ Lo FREQ 20–100–500 Hz This adjusts the center frequency when changing the sound quality in the low band.
AUDIO OUTPUT (page 13/15)
REVERB
LEVEL 0–127 This adjusts the return level from reverb of the audio. A setting of “0” results in no reverb applied.
TIME 0.0–1.0–5.0 sec This adjusts the length of the reverb.
TYPE ROOM, HALL
This species the type of reverb.
ROOM: Produces the natural reverberations of a highly resonant room.
HALL: Produces reverberations like that of a performance in a concert hall or other such space.
AUDIO OUTPUT (page 14/15)
REVERB SEND
LEVEL
CH1 SDI
:
CH3 SDI
CH3 HDMI
CH4 HDMI
AUDIO IN
MIC IN
0–100–127 This adjusts the send level of audio to Reverb.
AUDIO OUTPUT (page 15/15)
MASTERING OFF, ON This switches mastering on and o.
NOISE SUPPRESSOR 0–127 This adjusts the degree of application of the noise suppressor.
ENHANCER 0–127 This adjusts the degree of application of the enhancer.
Hi 0–127 This suppresses high-frequency distortion and adjusts the sound to have sustained tones.
Mid 0–127 This suppresses midrange distortion and adjusts the sound to have distinct tones.
Lo 0–127 This suppresses low-frequency distortion and adjusts the sound to have stable tones.
