Roland V-1SDI Reference Manual

Menu List
4
Setting item Value Explanation
PANEL LOCK (page 12/16)
These set whether individual knobs and A/B fader are subject to panel lock (ON) or not subject to panel lock (OFF).
VOLUME OFF, ON The following knobs and the A/B fader
OUTPUT FADE VOL OFF, ON [OUTPUT FADE] knob
CONTROL 1 VOL OFF, ON [CONTROL 1] knob
CONTROL 2 VOL OFF, ON [CONTROL 2] knob
A/B FADER OFF, ON A/B fader
MEMORY (page 13/16)
MEMORY PANEL LOAD OFF, ON
This sets whether the state of the operation panel is updated (ON) or not updated (OFF) when
a memory is recalled.
POWER ON LOAD 1–8
Selecting a memory number causes the settings at the selected memory number to be
recalled at startup.
MEMORY PROTECT OFF, ON
Setting this to “ON” protects the memory, making it impossible to saving settings to memory.
* When this is set to “ON,” the AUTO MEMORY feature is disabled.
AUTO MEMORY OFF, ON
Setting this to “ON” makes memory 1 function as a last memory. Settings are automatically
saved to memory 1 on exiting the menu or releasing the [MEMORY] button.
SYSTEM (page 14/16)
HDCP OFF, ON
When set to “ON,” copyright-protected (HDCP) video can be input. HDCP is also added to the
video that is output.
FRAME RATE 59.94, 50 This sets the frame rate.
FREEZE MODE ALL, SELECT This sets the operation mode for freezes.
DEINTERLACE MODE WEAVE, BOB This species the method used when converting interlaced input video to progressive video.
AUTO OFF OFF, ON
This sets the Auto O function on or o.
When set to “ON,” the power to the V-1SDI is automatically turned o if 240 minutes elapse
with no operation performed on the unit.
OUTPUT FADE ASSIGN VIDEO, V & A, AUDIO, BLACK / A
This species the function of the [OUTPUT FADE] knob.
VIDEO: Applies a fade to the main output video.
V & A: Simultaneously applies a fade to the main output video and adjusts the
volume level of output audio.
AUDIO: Adjusts the volume level of output audio.
BLACK / A: Turning counterclockwise applies a black fade to the main output video.
Turning clockwise adjusts the volume level of output audio.
SYSTEM (page 15/16)
PVW INDICATOR (*3) LABEL OFF, ON Setting this to “ON” displays labels identifying SDI and HDMI in the preview output.
TALLY OFF, ON Setting this to “ON” displays a tally border in the preview output.
AUDIO LEVEL METER OFF, UPPER, LOWER Setting this to “UPPER” or “LOWER” displays a level meter for audio in the preview output.
AUTO SCAN OFF, ON
This sets the Auto Scan function on or o.
When set to “ON,” channels 1 through 4 are switched automatically.
SCAN TIME 1–5–120sec When the Auto Scan function is on, this sets the video display interval.
TRANS TIME 0.0–0.5–4.0sec When the Auto Scan function is on, this sets the length of time for applying a video transition.
SYSTEM (page 16/16)
COLOR BAR OUTPUT OFF, ON Setting this to “ON” outputs a color bar.
TEST TONE OUTPUT
OFF, -20dB@1kHz, -6dB@1kHz,
0dB@1kHz
This sets the test tone to output.
A/B FADER CALIBRATE — This calibrates the A/B fader.
RS-232 PANEL STATUS OFF, ON
Setting this to “ON” always sends a QPL (8: ALL) RS-232 command (p. **) when switching
channels or switching bus A and bus B.
FACTORY RESET — This returns the unit to its factory defaults.
VERSION — This displays the version of the system program.
(*3) This is enabled only for output from the MULTI-VIEW connector (HDMI).

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
