22
Settings
Trigger Settings
Here’s how to make trigger settings so that the signals from the
pads can be accurately processed by the TD-50.
Specifying the Pad Type
You can specify the type of pad (trigger type) used by each trigger
input of the trigger bank.
Trigger type
The trigger type is a collection of various trigger parameters,
adjusted to values that are appropriate for each pad.
To obtain the optimal settings for the pad used with
each trigger input, specify the model (type) of pad that’s
connected.
Trigger bank
A trigger bank contains an entire set of settings for 14
triggers.
Reference
For more about trigger banks, refer to “Reference Manual”
(PDF).
1. Press the [TRIGGER] button.
2. Press the PAGE [UP] button several times to access the top
page.
3. Press the [F1] (BANK) button.
The TRIGGER BANK screen appears.
Trigger bank number
Trigger type
4. Select the pad whose settings you want to edit (p. 17).
You can also use the cursor buttons to make a selection.
Pad Explanation
K KICK
S SNARE
T1–4 TOM1–4
HH HI-HAT
C1, 2 CRASH1, 2
R RIDE
A1–4 AUX1–4
5. Use the [–] [+] buttons or the dial to specify the trigger
type.
* You can’t change the trigger type of a trigger input that’s
assigned to a pad that supports a digital connection.
Reference
For details on about trigger settings, refer to “Reference Manual” (PDF).
Adjusting the Sensitivity of a Pad
By adjusting the sensitivity of a pad you can adjust the balance
between the force of the strike and the loudness of the sound.
1. Press the [TRIGGER] button.
2. Press the PAGE [UP] button several times to access the top
page.
3. Press the [F3] (SENS) button.
The TRIGGER SENS screen appears.
4. Select the pad whose settings you want to edit (p. 17).
5. Use the cursor buttons to select “Sensitivity.”
6. Use the [–] [+] buttons or the dial to adjust the sensitivity.
Reference
For details on adjusting the pad sensitivity, refer to “Reference
Manual” (PDF).
