Roland V-Studio VS-20 - Amp & Effect Section

21
Panel Descriptions
fig.front01.eps
1. [COSM] button/indicator
This switches the effect between on and bypass.
If this indicator is lit, you will hear the input sound with
the effects. If the indicator is unlit, the effects will be
bypassed and you will hear the input sound only.
*The [COSM] button can be used when the included VS-20
Editor is running.
You can start up VS-20 Editor by pressing the [COSM]
button while using Guitar Tracks 4.
2. PATCH SELECT [ ][ ]
These buttons switch effect patches.
The PATCH SELECT [ ][ ] buttons can only be used
when the included VS-20 Editor is running.
AMP&EFFECT section
1
1
2
2
