9RolliBot 2-in-1 Electric Mop
Section 4 : Installation
4.1 – Attaching the mops
BeforeassemblingtheRolliBotelectricmop,ip
over the main body and attach the two rotation
mops and back mop.
4.2 – Assembling the handle
Check the alignment before inserting the
handle.
Insert the handle into the stem tube. The peg
of the handle should pop in place with a "click"
soundonceaffixed.
4.3 – Assembling the stem onto the
battery section
Check the alignment before inserting the
stem.
With the handled assembled, insert the stem
into the battery section. The peg under the stem
should pop in place with a "click" sound once
affixed.
4.4 – Assembling the battery section
onto the main body
Check the alignment before inserting the
battery section.
With the handled and stem assembled, insert the
battery section into the main body. The peg on
the main body should pop in place with a "click"
soundonceaffixed.
Handle
Stem Tube
Lock Hole
Peg
Peg
Peg
Battery Section
Lock Hole
Lock Hole
Main Body
Back Mop
Main Body
Rotation Mops
