—19—
Cables for connection
When connecting the cable, unplug the power cord of the projector and
external devices from the power outlet.
Audio output
Audio input
Audio input
Audio output
● Audio cable * ● VGA cable * ● BNCcable*
（*：This projector is not equipped with this cable.）
Video output
Signal source
equipment
Video inputBNC interface
Video input
Video input
COMPUTER IN
RS-232C
COMPUTER OUT
DVI
R/PR G/Y/VIDEO
H V
B/PB
USB1
USB2
AUDIO IN
R/C OUT
HDMI
AUDIO OUT R/C IN
HDBT
LAN
