ROLY CM8000 - Dimensions

Dimensions
Ceiling mounting holes
645
440
34
240 180
240
50
100
6-M6*12
322.5 322.5
200.6
214
13.4
Unit: mm
Use screws with a length of 8mm (minimum) to 10mm (maximum) for ceiling mounting.
Screw locking torque
M6)4±0.5 N.m
.
Projector
Insert the nut (M6)
Screw holes
Maximum length of the screw
Minimum length of the screw
Unit
mm
—25—
