5
hardware
Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw
diagrams (SHOWN ACTUAL SIZE). Pay close attention to the color of each screw. You may receive extra hardware with your unit.
417087
(1F) x 26
hidden cam
(2F) x 8
cam dowel
(1S) x 1
black 9/16” large head screw
(8F) x 18
cam screw
(1R) x 6
metal pin
(12P) x 20
cam cover
(8S) x 3
connector screw
(20P) x 8
screw cover
(5F) x 3
hidden connector
(10S) x 8
silver 1-1/8" fl at head screw
(13M) x 1
washer
(61M) x 1
safety drywall anchor
(60M) x 1
safety strap
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
