P
REFACE
748332-D Rosemount Analytical June 1997
P-7
NGA Non-Dispersive Infrared Analyzer
S
PECIFICATIONS
- P
HYSICAL
C
ASE
C
LASSIFICATION
:
General purpose for installation in weather-protected areas
D
IMENSIONS
:
See Outline and Mounting Dimensions, Figure 2-3
W
EIGHT
:
Standard: 11 kg (24.2 lbs.); extended: 12.5 kg (27.5 lbs.)
M
OUNTING
:
Inside a Platform or custom-installed in a panel
M
AXIMUM
L
ENGTH OF
LON C
ABLE
:
1600 m (1 mile) between Analyzer Module and Platform
See the Preface Section of the Platform manual for specifications regarding Platform
related components.
