I
NSTALLATION
2-4
June 1997 Rosemount Analytical 748332-DNGA Non-Dispersive Infrared Analyzer
.6
[15]
1.6
[40]
20.0
[508.0]
STANDARD
24.8
[628.7]
EXTENDED
17.41
[142.2]
STANDARD
22.41
[569.2]
EXTENDED
1.0
[25]
1.1
[27]
8.4
213
1.1
28
5.6
[143]
2.8
[71]
4.3
[109]
.5
[13]
1.1
[28]
6.0
[152]
.6
[15]
8.2
[208]
8.4
[213]
6.2
[157]
G. POWER CABLE TO NETWORK.
F. NETWORK CABLE CONNECTIONS TO PLATFORM.
E. PURGE GAS IN: 1/4" O.D. TUBE FITTING.
D. REFERENCE IN: 1/4" O.D. TUBE FITTING.
C. REFERENCE OUT: 1/4" O.D. TUBE FITTING.
B. SAMPLE OUT: 1/4" O.D. TUBE FITTING.
A. SAMPLE IN: 1/4" O.D. TUBE FITTING.
5. MODULE TO BE INSTALLED WITHIN
±
15
°
OF HORIZONTAL.
4. POWER REQUIREMENTS: 24 VDC 3.5 A.
3. ELECTRICAL INSTALLATION MUST BE IN COMPLIANCE WITH NATIONAL ELECTRICAL
CODE (ANSI/NFPA 70) AND/OR ANY APPLICABLE NATIONAL OR LOCAL CODES.
2. MODULE IS NOT WEATHERPROOF.
1. APPROXIMATE WEIGHT: 24.2 LB (11.0 kg).
DIMENSIONS
INCH
[mm]
F
IGURE
2-2 O
UTLINE AND
M
OUNTING
D
IMENSIONS
