Rosemount 1151 - Page 9

Mounting Screw into
Mounting Plate
Mounting Screw
into Housing
Strap Washer
Retaining Straps
Mounting Screws
Terminal Screws
(Mount into Transmitter
“Test” Terminal Block)
Mounting Plate
Meter (Meter May Be
Rotated in 90° Increments)
Cover Bushing
Cover Foam Spacer
FIGURE 1. LCD Meter Exploded View.
751-0264B
