Rosemount 8712E - Page 14

Quick Installation Guide
00825-0100-4664, Rev BB
January 2013
Rosemount 8712 / 8700 Series
14
Table 4. Rosemount Alignment Spacer Table
To order an Alignment Spacer Kit (qty 3 spacers) use p/n 08711-3211-xxxx along with the
Dash No. above.
Rosemount Alignment Spacer Table
Dash No.
Line Size
Flange Rating(in) (mm)
0A15 1.5 40 JIS 10K-20K
0A20 2 50 JIS 10K-20K
0A30 3 80 JIS 10K
0B15 1.5 40 JIS 40K
AA15 1.5 40 ANSI - 150#
AA20 2 50 ANSI - 150#
AA30 3 80 ANSI - 150#
AA40 4 100 ANSI - 150#
AA60 6 150 ANSI - 150#
AA80 8 200 ANSI - 150#
AB15 1.5 40 ANSI - 300#
AB20 2 50 ANSI - 300#
AB30 3 80 ANSI - 300#
AB40 4 100 ANSI - 300#
AB60 6 150 ANSI - 300#
AB80 8 200 ANSI - 300#
AB15 1.5 40 ANSI - 300#
AB20 2 50 ANSI - 300#
AB30 3 80 ANSI - 300#
AB40 4 100 ANSI - 300#
AB60 6 150 ANSI - 300#
AB80 8 200 ANSI - 300#
DB40 4 100 DIN - PN10/16
DB60 6 150 DIN - PN10/16
DB80 8 200 DIN - PN10/16
DC80 8 100 DIN - PN25
DD15 1.5 150 DIN - PN10/16/25/40
DD20 2 50 DIN - PN10/16/25/40
DD30 3 80 DIN - PN10/16/25/40
DD40 4 100 DIN - PN25/40
DD60 6 150 DIN - PN25/40
DD80 8 200 DIN - PN40
RA80 8 200 AS40871-PN16
RC20 2 50 AS40871-PN21/35
RC30 3 80 AS40871-PN21/35
RC40 4 100 AS40871-PN21/35
RC60 6 150 AS40871-PN21/35
RC80 8 200 AS40871-PN21/35
