Rosslare AC-G4 Series User Manual

Page 36
07/04
Deleting Primary and Secondary Codes using the Code Search
Method
1) Enter Programming Mode
2) Press "8" to enter Menu 8
!
The Mode LED will turn red
3) Enter the 3-digit User Slot 000
!
The Door LED will flash orange
The controller is now waiting for the Primary Code of the User
you want to delete.
4) Enter the 4-digit PIN Code of the
Primary Code belonging to the
user you want to delete.
!
The Mode LED will flash red
5) Enter your Programming
Code to confim the deletion.
If the Programming Code is valid, you will hear three beeps
and the AC-G43 will return to Normal Mode.
If the Programming Code is invalid, you will hear a long beep and
the AC-G43 will return to Normal Mode.
Note: - It is recommended that a record be kept of added and
deleted users so that it will be easier to keep track of
which user slots are empty and which user slots are not.
AC-G43
Mode Door
GREEN
Mode Door
ORANGE
RED
0
0
0
Mode Door
ORANGE
RED
?
?
?
?
Mode Door
ORANGE
RED
Lock Strike Relay and Auxiliary Relay
Code Assignment
When a Primary Code is enrolled for any user, that user is assigned
rights to activate the Lock Strike Relay when they present a valid
code to the controller. The Code Assignment Menu allows you to
assign whether the Lock Strike Relay and/or the Auxiliary Relay is
activated when a user enters a valid code. There are two methods
to Assign Codes, Standard Method and the Code Search Method.
Lock Strike Relay and Auxiliary Relay Code Assignment using
the Standard Method
1) Enter Programming Mode
2) Press "9" to enter Menu 9
!
The Mode LED will turn green
!
The Door LED will turn orange.
3) Enter the 3-digit User Slot that
you want to assign a code to.
!
The Door LED will flash green
4) Enter the assignment digit for the current User Slot:
"1" assigns the Lock Strike Relay only
"2" assigns the Auxiliary Strike Relay only
"3" assigns the Lock Strike and Auxiliary Relay
!
If the assignment code is valid
the Mode LED will stop flashing.
The controller is now waiting for another slot number. Press the
"#" key to go to the next slot or enter a new slot number, or if
you do not wish to continue press the "#" key for two times
and the controller will return to Normal Mode.
Page 37
07/04
AC-G43
Mode Door
GREEN
Mode Door
ORANGE
GREEN
?
?
?
Mode Door
ORANGE
GREEN
Mode Door
ORANGE
GREEN
?
?
?
?
