38 AC-Q4x Series Installation and Programming Manual
Table 3: Quick Reference Guide for Auxiliary Mode Setting
Auxiliary
Mode
Auxiliary
Input
Function
Auxiliary Output
Activated by
Auxiliary
Relay
Auxiliary Settings
(in seconds)
0 AUX REX Valid code or AUX
REX
N.O. 01 to 99 Aux. Relay
Release Time
00 Aux. relay toggle
1 Normal/Secure
switch
Valid code N.O. 01 to 99 Aux. Relay
Release Time
00 Aux. relay toggle
2 Normal/Secure
switch
Star button (*)
N.O. 01 to 99 Aux. Relay
Release Time
00 Aux. relay toggle
3 Normal/Secure
switch
Tamper event N.C. 01 to 99 Aux. Relay
Release Time
00 Aux. relay tamper
activated
4 Normal/Secure
switch
Direct shunt N.O.
01 to 99 Shunt time
5 Door Monitor Shunt N.C. 01 to 99 maximum
Shunt time
6 Door Monitor Forced door N.C. 01 to 99 Forced delay
7 Door Monitor Door ajar N.C. 01 to 99 Ajar delay
8 LED control –
Green
Valid code N.O. 01 to 99 Aux. Relay
Release time
00 Aux. relay toggle
9 LED control –
Red
Valid code N.O. 01 to 99 Aux. Relay
Release time
00 Aux. relay toggle
