AY-B91x0BT User Guide
9
2.2. Configuration Diagram
2.2.1. Standalone Use (Access)
2.2.2. Connecting to the PC server (Access, T&A)
TCP/IP
T&A Control Program
Internet /
WAN / LAN
TCP/IP
Fingerprint Authentication
Server
TCP/IP
Remote Administrator Program
(User and Terminal Setting
Management)
TCP/IP
TCP/IP
TCP/IP
12 V Unique
Adapter
Electrical Lock
(Lock+, Lock-, Monitor)
