Rotabroach COMMANDO 40 - 5) SPECIFICATION

Issue 2 Original version Sept 2020
- 6 -
5) SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 40mm dia. x 50mm deep
Arbor bore = 19.05mm (3/4”) dia.
Motor Unit
(Nominal values)
COMMANDO40/1
110V 50-60Hz
1100W
COMMANDO40/3
230V 50-60Hz
1100W
Electro Magnet
COMMANDO40/1
110V 50-60Hz
45W
COMMANDO40/3
230V 50-60Hz
45W
Overall
Dimensions
Height (maximum extended)
510 mm
Width (including Hand Wheel)
180 mm
Length Overall (including Guard)
265 mm
Magnet Footprint
165mm x 80mm
Nett Weight
14.6 kg
Stroke
85mm
No Load speed
All voltages
270-610 rpm
Tractive Force of Magnet at 20º C (25mm min. plate thickness)
The use on any material less than 25mm thick will progressively reduce the
magnetic performance. If possible substitute material should be positioned under
the magnet and work piece to equate to a suitable material thickness. If this is not
possible an alternative secure method of restraining the machine MUST be used.
Failure to do so may result in personal injury.
8000N
Maximum hand/arm vibration magnitude (measured at handle during operation in
accordance with ISO5349, using a 22mm dia cutter through a 13mm mild steel plate).
2.892 m/s²
Estimate of vibration exposure. Operation 30 holes @ 1 minute/hole.
0.13 m/s² A(8)
Average noise level during cutting at operator’s ear position.
L
PA
Max. 88.4 dB(A)
L
WA
Max. 101.4dB(A)
Vibration and Noise
The declared vibration total value(s) and the declared noise emission value(s) have been measured in accordance with a standard test
method and maybe used for comparing one tool with another.
The declared vibration total value(s) and declared noise emission values(s) may also be used in a preliminary assessment of exposure.
The vibration and noise emissions during actual use of the power tool can differ from the declared total value depending on the ways
in which the tool is used and especially what kind of workpiece is being processed
The need to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of
use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in
addition to the trigger time).
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when operating the
machine.
These tools are UK designed and manufactured with globally sourced components and conform to the requirements of
EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
