Issue 2 Original version Sept 2020

- 1 -

000

Magnetic drilling machine

Model Number COMMANDO40/1, COMMANDO40/3

This machine (Serial Number ...........................) is CE approved.

OSL Cutting Technologies

Burgess Road

Sheffield, South Yorkshire

United Kingdom

S9 3WD

Tel: +44 (0) 114 2212 510 Fax: +44 (0) 114 2212 563

Email: info@rotabroach.co.uk Website: www.rotabroach.co.uk

Table of Contents

Questions and Answers:

B
Brandon MillsJul 29, 2025
Why does the fuse blow when I start up my Rotabroach COMMANDO 40?
- J
  James RyanJul 29, 2025
  The fuse might blow when starting the motor due to several reasons. It could be caused by damaged or defective wiring, requiring you to check the wiring for any issues. Alternatively, the wrong value fuse might be installed, in which case you should replace it with the correct one. Other potential causes include a motor running roughly (inspect and address motor issues), a defective armature or field (replace if defective), worn-out carbon brushes (replace them), or a defective control unit (replace it).
L
Laura MooreAug 5, 2025
What to do if the fuse blows when the magnet switch is turned on in my Rotabroach Drill?
- V
  Victoria StanleyAug 6, 2025
  If the fuse blows when you turn on the magnet switch, it could be due to several reasons. First, check the wiring for any damage or defects. Other possible causes include using the wrong value fuse (replace it with the correct one), a defective magnet switch (replace it), a defective control unit (replace it), or a defective magnet (replace it).
T
Theresa WhiteAug 13, 2025
How to troubleshoot frame under voltage in Rotabroach Drill?
- S
  Steven MoodyAug 13, 2025
  If the frame is under voltage, it could be due to damaged or defective wiring (check the wiring), a defective magnet (replace the magnet), or a seriously dirty motor (clean the motor).

Rotabroach COMMANDO 40 Specifications

General

Model	COMMANDO 40
Type	Magnetic Drill
Drilling Capacity	40 mm
Speed	450 RPM
Twist Drill Capacity	13 mm
Voltage	230V / 110V

Summary

1) INTENDED USE

2-3) GENERAL SAFETY RULES

4) INFORMATION PLATE SYMBOLS

5) SPECIFICATION

6) OPERATIONAL SAFETY PROCEDURES

7) OPERATING INSTRUCTIONS

8) EXTENSION CABLE SELECTION

9) MOUNTING OF CUTTERS

10) REMEDIES FOR HOLE MAKING PROBLEMS

11) WIRING DIAGRAM

12) EXPLODED VIEW OF MACHINE

13) EXPLODED VIEW OF MOTOR AND GEARBOX

14) PARTS LIST

15) PIPE ADAPTOR KIT RD2311

16) FITTING THE CHUCK

17) MAINTENANCE

18) TROUBLE SHOOTING

19) CUTTER SELECTION AND SPEEDS

20) WARRANTY AND CE STATEMENT
