9
INSTALLATION METHOD
We very much recommend visiting this excellent video giving full details of unpacking & installation
• Hold the armrest unit up and hook Hanger 2 onto the carrier groove. Slowly push the armrest
unit back into the chair linkage until Hanger 2 aligns completely with Hanger 4. Insert Hanger
1 into Hanger 3 using a screw to secure the armrest into place. (Use the same procedure for
the other side)
• Before beginning installation, please verify that all components are included (check against
the Packing List carefully).
Step 1: Take all massage chair components and accessories out of the packaging
• Connect the numbered air hoses to the matching numbered nozzles on both the armrests and
plug in the air valve connector.
Step 2: Install Armrest Unit
Air Nozzle
Air Valve Plug
Air Hose
Air Valve Port
Armrest Unit
Linkage
Screw Hole
Hanger 3
Hanger 4
Armrest Unit
Hanger 2
Hanger 1
To Next Page
