Rotary DS35 User Manual

80
7.
Part.No Description Qty Dim
XX140075 Rubber pad 4 30mm
XX140076 Rubber pad 4 70mm
Other hydraulic components
Part.No Description Qty Remark
XX140010-15 Seal kit for cylinder XX140010 1
XX140011-15 Seal kit for cylinder XX140011 1
8.
Part.No Description Qty Dim
XX140009 Ramp roller 2 95mm L
XX130236 Ramp roller 4 30mm L
9.
Part.No Description Qty Dim
XX140010 Master Cylinder 2
XX140011 Slave Cylinder 2
PartNo. Description Qty Dim
FJ2427Y Rubber pad 4 38mm
FJ2428Y Rubber pad 4 76mm
SB700071Y Rubber pad 4 13mm
