6
3.4 Instructions for installation
- Position lift at a height of about 1m (39 in.).
- Keep rubber pad supports fully closed.
- Lift wheel-free jack as described in paragraph 2.1.
- Move it inside lift.
- Slowly lower wheel-free jack down to a distance of
about 5 cm (2 in.) from platform.
- Position wheel-free jack brackets (Fig. 4) close to
platforms edges.
- Lower wheel-free jack onto edge.
- Refer to Fig. 5 to find the holder bracket 1.
- Position holder bracket 1 Fig. 5.
- Holder bracket positioning operations shall be car-
ried out on both sliding members of wheel-free jack.
1
Fig. 4
Fig. 5
