Effectivity: 912 Series BRP-Powertrain page 3-3
OM Edition 2 / Rev. 0 April 01/2010
d04945.fm
Coolant level
Graphic Expansion tank
Fig. 1
05823
The coolant specifications of the section
Chapter 2.3) Operating media are to be ob-
served!
Step Procedure
1 Verify coolant level in the expansion tank, replenish as re-
quired up to top. The max. coolant level must be filled up
to the top (see Fig. 1).
2 Verify coolant level in the overflow bottle, replenish as re-
quired.
The coolant level must be between max. and min. mark.
Part Function
1 radiator cap
2 expansion tank
