Effectivity: 912 Series BRP-Powertrain page 7-6
OM Edition 2 / Rev. 0 April 01/2010
d04679.fm
Oil system
Fig. 3 08650
7
5
1
6
8
3
2
4
Part Function
1 pressure regulator
2 oil pressure sensor
3 oil pump
4 oil tank
5 oil cooler
6 oil filter
7 venting tube
8 oil temperature sensor
