Rotel A11 - Getting Started

8
A11 Stereo Integrated Amplier
About Rotel
Our story began over 50 years ago. Over the decades, we have received
hundreds of awards for our products and satised hundreds of thousands
of people who take their entertainment seriously – like you.
Rotel was founded by a family whose passionate interest in music led them
to manufacture high-delity components of uncompromising quality.
Through the years, that passion has remained undiminished and the family
goal of providing exceptional value for audiophiles and music lovers,
regardless of their budget, is shared by all Rotel employees.
Rotel’s engineers work as a close team, listening to, and ne tuning, each
new product until it reaches their exacting musical standards. They are
free to choose components from around the world in order to make that
product the best they can. You are likely to nd capacitors from the United
Kingdom and Germany, semiconductors from Japan or the United States,
while toroidal power transformers are manufactured in Rotel’s own factory.
We all have concerns about our environment. And, as more and more
electronics are produced it is especially important for a manufacturer to do all
it can to engineer products that have a minimum impact on the environment.
At Rotel, we are proud to do our part. We have reduced the lead content
in our products by using special lead-free ROHS solder and components.
Our engineers continually strive to improve power supply efciency without
compromise to quality. When in standby mode Rotel products use minimal
power to meet global Standby Power Consumption requirements.
The Rotel factory is also doing their part to help the environment through
constant improvements to product assembly methods for a cleaner and
greener manufacturing processes.
All of us at Rotel thank you for buying this product. We are sure it will bring
you many years of enjoyment.
Getting Started
Thank you for purchasing the Rotel A11 Stereo Integrated Amplier. When
used in a high-quality music audio system, Rotel products will provide years
of musical enjoyment.
This amplier is a full featured, high performance component. All aspects
of the design have been optimized to retain the full dynamic range and
subtle nuances of your music. The un it has a highly regulated power supply
incorporating a Rotel custom-designed toroidal power transformer. This low
impedance power supply has ample power reserves, which enables the
amplier to easily reproduce the most demanding audio signals. This type
of design is more expensive to manufacture, but it is better for the music.
The printed circuit boards (PCB) are designed with Symmetrical Circuit
Traces. This ensures that the precise timing of the music is maintained and
faithfully recreated. The circuitry uses metal lm resistors and polystyrene
or polypropylene capacitors in important signal paths. All aspects of this
design have been examined to ensure the most faithful music reproduction.
The main functions of the A11 are easy to install and use. If you have
experience with other stereo systems, you shouldn’t nd anything perplexing.
Simply plug in the associated components and enjoy.
Contents
Important Safety Instructions ..........................................2
Figure 1: Controls and Connections 3
Figure 2: Remote Control RR-AX1401 4
Figure 3: Preamp Input and Speaker Output Connections 5
Figure 4: 12V Trigger Connections 6
Important Notes 7
About Rotel .......................................................8
Getting Started ....................................................8
A Few Precautions 9
Placement 9
Cables 9
The RR-AX1401 Remote Control ........................................9
Second Amplier Remote Code 9
Remote Control Batteries 9
AC Power and Control ...............................................9
AC Power Input
o
9
Power Switch
1
A
and Power Indicator
2
10
12V Trigger Connection
e
10
Protection Indicator
2
..............................................10
Input Signal Connections ............................................10
Phono Input
0
and Ground Connection (GND)
9
10
Line Level Inputs
-=t
10
Preamp Output
y
................................................10
Speaker Outputs
ui
.............................................10
Speaker Selector Switch
4
10
Speaker Selection 10
Speaker Wire Selection 10
Polarity and Phasing 10
Speaker Connection 11
Headphone Output
3
..............................................11
Display
5
......................................................11
APTX Bluetooth Connection
q
........................................11
Audio Controls ....................................................11
Volume Control
6
E
11
Balance Control
8
B
11
Source Input Selector
7
I
11
Tone Control .....................................................11
Tone Bypass 11
Tone Enabled 11
Tone Rotel Boost 12
Tone Rotel Max 12
Bass and Treble Controls
8B
12
Dimmer Control ...................................................12
Display Dimmer
8
D
12
LED Dimmer
8 12
EXT REM IN Jack
w
...............................................12
RS232 Connector
r
...............................................12
Settings Menu ....................................................12
Troubleshooting ...................................................13
Power Indicator Is Not Illuminated 13
Fuse Replacement 13
No Sound 13
Playable Audio Formats 13
Cannot Connect via Bluetooth 13
Specications .....................................................14
