Rotel S14 - Product Controls and Connectivity; Front Panel Controls Overview; Rear Panel Connectivity Ports

3
Figure 1: Controls and Connections
Commandes et Branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
Controlli e connessioni
De bedieningsorganen en aansluitingen
Kontroller och anslutningar
Органы управления и разъемы
100-120V/220-240V~50/60Hz
MODEL: S14
PRODUCT NAME: INTEGRATED NETWORK STREAMER
POWER CONSUMPTION: 280W
MADE IN CHINA
OFF
5V/2.0A
OUT OUTIN
PRE
SUB
AC FUSE: T8AL/250V
CAUTION :
Replace with same type
T8AL/250V fuse
Contains FCC ID: 2ADBM-LS10 Contains IC: 20276-LS10
Contains FCC ID: XCO-HSBT075 Contains IC: 7756A-HSBT075
8
9
0 - =
q
r
u
o
i
1
2 3
4 5
6
7
w e
yt
1
: Power Button
Activate the unit or put it into standby mode
2
: Power LED
3
: Headphone Output
Connect headphones for private listening.
4
: Source Button
Selects the input signal source.
5
: Display
6
: Volume Knob
Adjust the volume output level.
7
: MENU and - / + buttons
Access the various menus and operate the
Amplier settings.
8
: Bluetooth Antenna
Use for wireless streaming via Bluetooth.
9
: COAX Input
0
: OPTICAL Input
-
: PC-USB input
=
: NETWORK port
q
: USB Power Port
Use for audio playback via Flash Drive.
w
: Wi-Fi Antenna
Use for wireless connection.
e
: Master Power Switch
r
: AUX input
Analog “line level” input.
t
: PRE Output
Connect to the integrated amplier
or power amplier.
y
: SUB Output
Connect to a subwoofer.
u
: Speaker Connectors
i
: Fuse holder
o
: AC Power Inlet
