Rotex QTF Series User Manual

RTX-IOM-QTF-R01-0217
Page 25 of 26
www.rotexautomation.com
NOTE:
1. ‡ Marked components are the parts of the seal kit.
2. ◊ Marked components are the parts of repair kit.
3. ♦ Marked components are critical components.
ITEM NO.
DESCRIPTION
MATERIAL
SPECIFICATION
QTY.
1
BODY
ALUMINUM
6063T6
1
2♦
PINION
STEEL
EN8
1
3♦
PISTON WITH RACK
ALUMINUM
LM6
2
4♦
COVER
ALUMINUM
LM6
2
5
STOPPER BOLT
STEEL
AISI304
2
6‡◊
O-RING
NBR
-
2
7◊
PISTON STRIP
POLYACETAL
-
2
8♦
CAM
CAST CARBON STEEL
ASTM A216 GR WCB
1
9
COVER BOLT
STEEL
AISI304
8
10
WASHER
POLYACETAL
-
1
11‡◊
O-RING
NBR
-
1
12
RACK BEARING
POLYACETAL
-
2
13
NUT
STEEL
AISI304
2
14‡◊
O-RING
NBR
-
1
15
PINION STRIP
POLYACETAL
-
1
16◊
COVER SEAL
NBR
-
2
17
CIRCLIP
SPRING STEEL
DIN 471
1
18◊
BEARING BUSH
POLYACETAL
-
1
19
WASHER
STEEL
AISI304
1
20
INNER SPRING
STEEL
-
2
21
MIDDLE SPRING
STEEL
-
2
22
OUTER SPRING
STEEL
-
2
23‡◊
O-RING
NBR
-
2
24
WASHER
STEEL
AISI304
2
25
BODY RING
POLYACETAL
-
1
