Rotex QTF Series User Manual

RTX-IOM-QTF-R01-0217
Page 9 of 26
www.rotexautomation.com
5. Installation
WARNING: Do not remove spring module while spring is compressed
NOTE:
 Ensure the installation meets the legal and regulatory requirements of
the country and state of use.
 Until the actuator is installed, keep it in its original packaging and stored
between 4°C and 49°C (40 °F and 120 °F).
 Ensure the operating medium meets the requirements, described in
service information (heading 4).
 Use proper rigging to handle the actuators weighing more than 30 kg (66
lb) to avoid personal injury.
5.1 Mounting
 Keep the valve on which the actuator is to be mounted in home position, until the
installation is complete. Ensure that valve is secure.
 Fix the brackets on the valve.
 Ensure the coupling slides on the stem smoothly without any play.
 Check the other end of the coupling with the actuator for the length of engagement.
 Mount the actuator on the bracket with fasteners.
 Tighten all the fasteners to the torque as shown below.
Sr. no.
Actuator model
Bolt size (#9)
Tightening torque (Nm)
1
QTF 32
M6
8
2
QTF 40
3
QTF 50
4
QTF 63
5
QTF 80
6
QTF 90
M8
20
7
QTF 100
8
QTF 110
9
QTF 125
10
QTF 150
M10
40
11
QTF 175
12
QTF 200
M12
70
13
QTF 250
14
QTF 300
15
QTF 350
