8 x Technical data
8 Technical data
8.1 Basic data
8.1.1 Sanicube (SC)
Unit SC 538/0/0 SC 538/16/0 SC 538/16/16
Basic data
Total storage capacity litres 500
Empty weight kg 79 85 91
Total filled weight kg 579 585 591
Dimensions (L x W x H) cm 79 x 79 x 164
Maximum permissible storage water temperature °C 85
Heat consumption at stand-by and at 60 °C kWh/24 h 1.4
Drinking water heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 24.5
Maximum operating pressure bar 6
Domestic water heat exchanger surface m
2
5
1. Storage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres — 10.6
Heat exchanger surface area m
2
—2.1
2. Storage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres — — 10.4
Heat exchanger surface area m
2
——2.3
Thermal output data
N
L
efficiency characteristic acc. to DIN 4708
1)
— 4.1 4.4 / 4.8
2)
Continuous output Q
D
according to DIN 4708 kW — 35 50 / 50
2)
Maximum draw-off rate for the duration of 10 min on recharging
at 35 kW (T
KW
= 10 °C / T
WW
= 40 °C / T
SP
= 60 °C)
l/min — 30 31 / 34
2)
Hot water quantity without reheating at 15 l/min draw-off rate
(T
KW
= 10 °C / T
WW
= 40 °C / T
SP
= 60 °C)
litres — 420
Hot water volume with post-heating at 15 l/min draw-off rate
(post-charge output 20 kW) (T
KW
= 10 °C / T
WW
= 40 °C /
T
SP
= 60 °C)
litres — 970
Short-term water quantity in 10 min litres 300 310
Pipe connections
Cold and hot water inches 1" Outer thread
Heating feed and return flow inches 1" Outer thread
Order number 16 52 01 16 52 02 16 52 03
Tab. 8 -1 Basic data Sanicube
1) With post-charging at 35 kW, 80°C flow temperature, 65°C storage tank temperature,
45°C hot water temperature; 10°C cold water temperature.
2) With parallel connection of both storage tank charging heat ex-
changers.
3) Data applies to draw-off rate of 20 l/min.
