92 Royal Enfield Himalayan
MINOR MAINTENANCE TIPS
n
Measure the drive chain free
play on the top run of the
chain.
n The recommended free play
is 20 to 30 mm.
To adjust the chain tension and
free play:
n Loosen rear wheel spindle
nut.
n Loosen lock nutsof the
chain adjuster on both ends
of the swing arm.
n
Tighten / loosen the adjuster nut on left swing arm end,
to reduce / increase chain tension.
n Ensure the ground is level & firm and place the
motorcycle in its center stand.
n Rotate wheel slowly and check chain free play at the
top run to be between 20 - 30 mm.
WARNING
Please follow instructions as per periodical maintenance.
DRIVE CHAIN TENSION (FREE PLAY 20-30 mm)
