Royal Enfield Meteor 350 2023 User Manual

Royal Eneld Meteor 350
94
REAR SUSPENSION SETTING
 Rest the motorcycle on
center stand.
 Ensure the tyre pressure
is at recommended
specification.
 Ensure adjuster are clear
of all dirt and debris
before adjusting, if they have dirt or debris please
clean it suitably before adjusting.
 The adjuster is a 6 step adjuster and it is kept at
first notch position.
 Adjust shock preload by rotating the adjuster
clockwise using CSpanner to increase the preload.
 Adjust shock preload by rotating anti-clockwise
using CSpanner to decrease preload (to make it to
first notch position).
 Make the same adjustments on both sides, uneven
adjustment may lead to discomfort to the rider.
Loosen Tighten
NOTE
 Adjusting the
suspension requires
a C-spanner. It is we
recommend to use the
C-spanner that is given
in your vehicle tool
kit. Extension tube to
be used for leverage
purposes.
 The best spring preload setting is achieved when
it is set for the weight of the rider and that of any
luggage and a passenger.
 We recommend to increase the preload and keep
it at final notch for fully loaded (GVW condition),
thus ensuring an ideal compromise between
handling and stability.
Adjuster

Royal Enfield Meteor 350 2023 Specifications

General

Engine Type	Single Cylinder, 4 Stroke, Air-Oil Cooled
Displacement	349 cc
Max Power	20.2 bhp @ 6100 rpm
Max Torque	27 Nm @ 4000 rpm
Transmission	5-speed constant mesh
Fuel System	Electronic Fuel Injection (EFI)
Front Suspension	Telescopic, 41mm forks, 130mm travel
Fuel Tank Capacity	15 liters
Kerb Weight	191 kg
Seat Height	765 mm
Tyre Size (Front)	100/90 - 19
Tyre Size (Rear)	140/70 - 17
Ground Clearance	170 mm
Wheelbase	1400 mm
Rear Suspension	Twin shock absorbers with 6-step adjustable preload
Front Brake	300mm Disc, Twin Piston Floating Caliper
Rear Brake	270mm Disc, Single Piston Floating Caliper
ABS	Dual Channel ABS
