ROYAL ENFIELD WORKSHOP MANUAL
MODEL YEAR
CARB
NUMBER
CHOKE
DIAMETER
MAIN
JET
NEEDLE
JET
NEEDLE
P OSIT ION
THROTTLE
VALVE
250 MODEL S 1951-53 274BH/3A 25/32 75 106 2 4 STUB FITTING
250 MODEL S 1951-53 274BS/3A 25/32 75 106 2 4 FLANGE FITTING
250 CLIPPER 1954-55 274BS/3A 25/32 75 106 2 4 FLANGE FITTING
250 CLIPPER 1955-57 375/10 25/32 120 105 3 4 PILOT JET 25
Section F1
SECTION F1
AMAL NEEDLE TYPE CARBURETTER
