ROYAL ENFIELD WORKSHOP MANUAL
Section M3 Page 1
SECTION M3
Special Tools
For "250 Clipper"
SECTION C3
Sub-
Section No. Use Page
11 E.5477 Gudgeon Pin Extractor 1
16 E.5425 Pump Disc Lapping Tool 1
17 E.5451 Pump Worm Spanner 1
18 14835 Magneto Sprocket Extractor 1
23 E.4871 Brake Bar for Clutch Centre 1
23 E.5414 Extractor for Clutch Centre 1
SECTION D3
4 E.4816 Tool for fitting Timing Side Roller Race 2
4 E.5119 Tools for fitting Roller Race to Driving Side
Crankcase 2
5 E.6462 Locating Plate for Assembly of Cam Spindles 3
6 E.2775 Flywheel Assembly Pot or Jig 3
SECTION HI
5 E.5431 Frame Expander 4
SECTION J2
2 E.5417 Gland Nut Hand Grips 4
2 E.5418 Lockring Spanner 4
www.hitchcocksmotorcycles.com

Royal Enfield SPRING FRAME O.H.V. 250cc CLIPPER 1954 Specifications

General

Displacement	248cc
Compression Ratio	6.5:1
Ignition	Magneto
Frame Type	Spring frame
Suspension Front	Telescopic forks
Suspension Rear	Rigid
Brakes Front	Drum
Brakes Rear	Drum
Engine Type	Single cylinder, overhead valve (OHV)
Transmission	4-speed
Top Speed	70 mph
Wheelbase	1350 mm
Weight	137 kg (302 lbs)
Fuel Capacity	3.5 gallons
