Circuit Board Pin Location · Color · Function
1 blue/orange battery relay
2 yellow/14 gauge radio memory
3 red/black TV power
4 green/yellow vanity light
5 white/blue reading light
6 blue/red ignition switch
7
8 green/white aux battery power
9 red/14 gauge stereo power
J-9 Plug
J-10 Plug
1 orange/black console lights
2 green/orange halo lights
3 blue/white heat valve
4 yellow/red 12v b
5 violet/white 12v a
6 orange a/c 1 high
7 orange a/c 1 high
8
9
J-11 Plug
1 green sunroof (+)
2
3
4
5 blue/brown privacy (+)
6
7 red/green oor light
8
9 blue/yellow console
10 white/brown privacy (-)
10 red/black TV/VCR
11 red/white 12v a switched
12 brown/white coach light
13 brown coach light trigger
14 red 12v c switched
15 purple/black intercom power
10 orange a/c 2 high
11
12 orange a/c 1 high
13
14 yellow/blue freon valve 1
15 red/yellow a/c clutch
11 black/white sunroof (-)
12
13 blue/green glass motor (+)
14 white/green glass motor (-)
15 blue/black dome light
21
