FUSES
Green/White
Red, 4 Ga
Blue/Orange
Red, 16 Ga
Terminal
(+)
Red, 8 Ga
(-)
Power to Board
Battery
Spare
Engine Block
(+)
Ground at
Black, 4 Ga
Diode
Diode
16 Ga
SOLENOID
Auxiliary Battery
Power to Board
Battery Relay
Red, 4 Ga
2 - 50 AMP
16 Ga
TOWN CAR / CADILLAC
DUAL BATTERY
(-)
Red, 4 Ga
Positive
* TownCar: Under the hood
* Cadillac: Under the Rear Seat
Location
to Board
(Trigger Wire)
Power to Board
POWER FUSE MODULE
PART No DESCRIPTION QTY
HC5108 1/4 - 20 x 2 Bolt 1
FEN106 1/4 x 1 1/2 Fender Washer 1
NLN109 1/4 - 20 NYLOK Lock Nut 1
LWL108 1/4 Lock Washer 1
SOLENOID
PART No DESCRIPTION QTY
HC5129 5/16 - 18 x 1/2 Bolts 2
FWL108 1/4 FLAT USS Washer 2
NLN110 5/16 - 18 NYLOK Lock Nuts 2
KN110
5/16 - 24 KEPSNUT
Solenoid Studs - Power
2
KN105
10-32 KEPSNUT
Solenoid Studs - Coil Exciter
2
Red, 8 Ga
E
F
E
F
D
C
B
A
B
C
D
12345678
8 7 6 5
4
3
2 1
A
ENG APPR.
CHECKED
MFG APPR.
Q.A.
UNLESS OTHERWISE SPECIFIED:
SCALE:
COMMENTS:
DWG. NO.
C
SIZE
Drawn byRevision #DescriptionsGroupsModelYearBrand
TITLE:
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
ROYALE. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF ROY ALE IS PROHIBITED.
PROPRIETARY AND CON FIDENTIAL
NEXT ASSY
USED ON
APPLICATION
DIMENSIONS ARE IN INCHES
TOLERANCES:
THREE PLACE DECIMAL
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
INTERPRET GEOMETRIC
TOLERANCING PER:
MATERIAL
FINISH
DM
2Alternator
110
1007
1
T-110-010-02
08/19/2008
TOWN CAR / CADILLAC
DUAL BATTERY
SCHEMATIC
SHEET 1 OF 1
